7.2 Air Compressor Option
Specifically designed for laser engravers, the air compressor utilizes an oil-free diaphragm.
The air compressor helps eliminate harmful and potentially damaging moisture from the laser optics,
maximizing laser optic life. In addition the air compressor provides the optimal air flow to the
SmartAIR nozzles to minimize flaming, suppress working temperatures, and blow away dust and particle
byproducts generated from the laser process.
Power Cord B
1/4" Air Inlet Tubing
Power Cord A
INSTALLATION:
1) Remove the plugs on the air compressor to expose the air inlets.
2) Fasten the included air tube fastener valve to the outgoing air inlet (indicated by 2a) and the air
filter into the ingoing air inlet (indicated by 2b).
