5.2.3.7 C180II Print Driver >> Stamp Page
Producing stamps require different operational steps than your standard engraving or cutting jobs.
The
Stamp page offers dynamic options allowing you to customize your stamp production process.
NOTE
The Stamp page will only appear and be accessible when you have selected the
Stamp
Mode from the Options Page.
Tip
Functions located on the other pages that are useful when making a
stamp: Set Shoulder, Pitch, Border, Invert, and Mirror.
Pitch
(Stamp
Page)
Your stamp will be a reversed image composed of engraved depressions and ridges. Think of
these ridges as the "contact sections" of the stamp. If the ridges of these contact sections are too
thin, they may break. The Pitch setting allows you to increase the width of the ridge base, hence
creating more stable "contact sections" and longer lasting stamp. The pitch value setting allows
you to adjust the base width of the ridge. Broad pitch gives the maximum amount of support for
each ridge. Experiment
with different pitch value settings in order to produce the stamp that is
best suited for your application.
Ridge: contact area of the
stamp
Base of ridge (pitch)
Slope of ridge (shoulder level)
