128 232001840G(08)
B. Detach the circular cylindrical cone by moving it in the direction of the arrow as shown
below.
C. Assemble the smaller conical fixture onto the rotary attachment as shown below.
D. Use the flat surface as shown in picture below as a reference point and tighten the first
screw against it. After doing so, tighten the second screw and the rotary attachment is
ready for use.
Flat surface
1. Tighten this against the flat
To Next Page
