116 MDS™ Master Station MDS 05-6399A01, Rev. F
Exception and Alarm States
The first indication of a problem is usually an illuminated ALARM LED on one or more of the
modules. The first place to look is the Alarm or Alarm/Relay module and see if the PWR/Alarm
LED is RED.
Table 8-2. Status LEDs – Exception and Alarm States
Module
LED
Behavior
Meaning
Troubleshooting Action
Platform Manager
PWR
Flashing
(BLUE)
Booting / System
Initialization
Wait several minutes for
system to boot.
Platform Manager
ALARM
Flashing
(BLUE)
Master Station Alarm
Use Device Manager to
determine Alarm
SD Radio Module
PWR/ALARM
Flashing
GREEN
Radio power up
Wait several seconds for radio
to boot.
SD Radio Module
PWR/ALARM &
ACTIVE
Alternating
Radio Firmware
update
Wait several minutes for
firmware upgrade to complete.
ALL Radio Modules
PWR/ALARM
Flashing RED
Radio Alarmed
Use Device Manager to
determine Alarm
ALL Radio
Module(s)
ACTIVE
Both/Only
Modules OFF
No active radio in the
system (Alarm/Relay
Module may still
indicates Active A or
B)
Select Radio with A/B Toggle
Switch. Return to Auto
(Redundant System)
Remove and re-seat radio
module.
Both Radio
Modules
(Redundant Only)
ACTIVE
Both
Modules
GREEN
System ERROR - both
radios active
(Alarm/Relay Module
may still show only one
active)
Select Radio with A/B Toggle
Switch. Return to Auto
Remove and re-seat one or
both radio modules.
Alarm Module
ALARM MAJ.
ALARM MIN.
RED
Master Station Major
or Minor Alarm.
Use Device Manager to
determine Alarm
8.2 Redundant Units
The active radio can be identified by the corresponding LED on the alarm/relay module as well
as the active LED on the radio module. The active unit is normally selected automatically. For
troubleshooting, the toggle switch can be used to manually set the active radio. Alternatively, the
switch can remain in the automatic position, and the active radio can be selected via the web UI,
or CLI.
8.3 Technical Assistance
Factory technical assistance is available by contacting GE MDS during business hours (8:30 AM
to 6:00 PM Eastern Time). For telephone assistance, call (585) 241-5510, or visit our website at
www.gemds.com for additional contact options.
8.4 Replacing Modules
Component-level repair of a transceiver board in the field is not recommended due to the
complex nature of the circuitry and the use of surface-mount technology throughout the radio.
You should return malfunctioning assemblies to the factory (or authorized service center) for
repair or replacement.
