6.0 MASTER STATION MODULES
The available modules are listed below and described in the following sections. To aid
identification, most modules have their 4-digit base part number printed on the faceplate. These
are the 4 numeric digits following 03- prefix.
Table 6-1. Available Modules
Identifier
Item
Description
6755
100-220V AC Power Supply Module
100-220 VAC, 50/60 Hz. 120W Max AC Power Supply
Module. Spare power supply can be used in either of two
power supply slots of the MDS™ Master Station.
6834
Platform Manager Module
Provides management and data interface functions.
6837
Duplexers
Spare duplexer in tray wired for MDS™ Master Station.
6843
+/- 12-36 V DC Power Supply Module
+/- 12-36 VDC. 10 A Max. DC Power Supply Module. Spare
power supply can be used in either of two power supply
slots of the MDS™ Master Station.
6844
+/- 36-75 V DC Power Supply Module
+/- 36-75 VDC. 3.5 A Max DC Power Supply Module. Spare
power supply can be used in either of two power supply
slots of the MDS™ Master Station.
6845
+/- 75-140 V DC Power Supply Module
+/- 75-140 VDC. 2 A Max DC Power Supply Module. Spare
power supply can be used in either of two power supply
slots of the MDS™ Master Station.
6846
Narrowband Radio Module: SMD9,
SDM4, LN9, LN7, or LN4
Full duplex SD-compatible radio module or LN-compatible
QAM radio module
6847
Redundant Alarm/Relay Module
Active radio relay and alarm/audio interface.
6848
None-Redundant Alarm Module
Non-redundant—Alarm and audio interface.
