Table 3-4. RF-45 to DB-9F Pin Out
Signal
RJ-45
DB-9F
Standard RS-232
DSR
1
6
DSR
DCD
2
1
DCD
DTR
3
4
DTR
Ground
4
5
Ground
RXD
5
2
RXD
TXD
6
3
TXD
CTS
7
8
CTS
RTS
8
7
RTS
No connection
N.C.
9
RI
Mini USB
The Mini USB port can be used to management the radio through a scriptable command line
interface (CLI) using the proper USB drivers available at www.gemds.com. Connect to the
management PC using the included Mini USB Cable. Once the PC registers the device driver,
the port will auto baud. The USB port provides CLI management only and cannot be used for
network diagnostics or for payload data.
Alarm Output and 4-Wire Audio
Alarm and audio signals are provided on the Alarm or Alarm/Relay module. Refer to Table 6-20
for details on pinout and signal descriptions. Audio signaling and alarm outputs are software
configurable. Refer to Section 5.0 Device Management for more information.
