12-4 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
COMPATIBILITY MODE CHAPTER 12: ABOUT THE MODBUS MEMORY MAP
030E 782 30783 Ib Diff
030F 783 30784 Ic Diff
0320 800 30801 Hottest Stator RTD Temp (°C)
0321 801 30802 RTD 1 (°C)
0322 802 30803 RTD 2 (°C)
0323 803 30804 RTD 3 (°C)
0324 804 30805 RTD 4 (°C)
0325 805 30806 RTD 5 (°C)
0326 806 30807 RTD 6 (°C)
0327 807 30808 RTD 7 (°C)
0328 808 30809 RTD 8 (°C)
0329 809 30810 RTD 9 (°C)
032A 810 30811 RTD 10 (°C)
032B 811 30812 RTD 11 (°C)
032C 812 30813 RTD 12 (°C)
0330 816 30817 Hottest Stator RTD Temp (°F)
0331 817 30818 RTD 1 (°F)
0332 818 30819 RTD 2 (°F)
0333 819 30820 RTD 3 (°F)
0334 820 30821 RTD 4 (°F)
0335 821 30822 RTD 5 (°F)
0336 822 30823 RTD 6 (°F)
0337 823 30824 RTD 7 (°F)
0338 824 30825 RTD 8 (°F)
0339 825 30826 RTD 9 (°F)
033A 826 30827 RTD 10 (°F)
033B 827 30828 RTD 11 (°F)
033C 828 30829 RTD 12 (°F)
0340 832 30833 J2 Vab
0341 833 30834 J2 Vbc
0342 834 30835 J2 Vca
0343 835 30836 J2 V AVG L-L
0344 836 30837 J2 Van
0345 837 30838 J2 Vbn
0346 838 30839 J2 Vcn
0347 839 30840 J2 V AVG L-N
0348 840 30841 Frequency
0370 880 30881 Pwr1 PF
0371 881 30882 Pwr1 Real
0374 884 30885 Pwr1 Reactive
0376 886 30887 Pwr1 Apparent
0377 887 30888 Pwr1 Pos WattHours
0379 889 30890 Pwr1 Pos VarHours
037B 891 30892 Pwr1 Neg VarHours
0390 912 30913 Cur1 Ph A Demand
0392 914 30915 Pwr1 Real Dmd
469 HEX 469 Decimal Modicon Format
(Needed for User Map)
Description
