GE Multilin 869 - Common Data Class Specifications for Measurand Information

CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS MICS
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE B-45
(889)
3.2 Common data class specifications for measurand information
3.2.1 Measured Value (MV)
ACD_3
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
general Boolean ST dchg M
dirGeneral Enumerated
(Byte)
ST dchg unknown | forward |
backward | both
M
q Bvstring13 ST qchg M
t Utctime ST M
configuration, description and extension
d Vstring255 DC O
dataNs Vstring255 EX M
MV_0
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
measured attributes
instMag FloatAnalogueValue MX ------ O
f FLOAT32 GC_1
mag FloatAnalogueValue MX dchg M
f FLOAT32 GC_1
range ENUMERATED(Byte) MX dchg O
q BVstring13 MX qchg M
t Utctime MX M
configuration, description and extension
units Unit CF O
SIUnit ENUMERATED(Byte) M
Multiplier ENUMERATED(Byte) O
db INT32U CF O
zeroDb INT32U CF O
rangeC RangeConfig CF O
hhLim FloatAnalogueValue
f FLOAT32 GC_1
hlim FloatAnalogueValue
f FLOAT32 GC_1
lLim FloatAnalogueValue
f FLOAT32 GC_1
llLim FloatAnalogueValue
f FLOAT32 GC_1
min FloatAnalogueValue
f FLOAT32 GC_1
max FloatAnalogueValue
