B-46 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS
(869)
(869)
f FLOAT32 GC_1
limDb INT32U
d Vstring255 DC O
MV_1
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
measured attributes
instMag FloatAnalogueValue MX ------ O
f FLOAT32 GC_1
mag FloatAnalogueValue MX dchg M
f FLOAT32 GC_1
range ENUMERATED(Byte) MX dchg O
q BVstring13 MX qchg M
t Utctime MX M
configuration, description and extension
units Unit CF O
SIUnit ENUMERATED(Byte) M
Multiplier ENUMERATED(Byte) O
db INT32U CF O
zeroDb INT32U CF O
rangeC RangeConfig CF O
hhLim FloatAnalogueValue
f FLOAT32 GC_1
hlim FloatAnalogueValue
f FLOAT32 GC_1
ILim FloatAnalogueValue
f FLOAT32 GC_1
IILim FloatAnalogueValue
f FLOAT32 GC_1
min FloatAnalogueValue
f FLOAT32 GC_1
max FloatAnalogueValue
f FLOAT32 GC_1
limDb INT32U
d Vstring255 DC O
dataNs Vstring255 EX M
MV_2
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
measured attributes
mag FloatAnalogueValue MX dchg M
f FLOAT32 GC_1
q BVstring13 MX qchg M
t Utctime MX M
