CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS MICS
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE B-47
(869)
3.2.2 Complex Measured Value (CMV)
configuration, description and extension
d Vstring255 DC O
dataNs Vstring255 EX M
MV_5
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
measured attributes
mag FloatAnalogueValue MX dchg M
f FLOAT32 GC_1
q BVstring13 MX qchg M
t Utctime MX M
configuration, description and extension
d Vstring255 DC O
dataNs Vstring255 EX M
CMV_0
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
measured attributes
instCVal FloatVector MX ------ O
mag FloatAnalogueValue
f FLOAT32
cVal FloatVector MX dchg M
mag FloatAnalogueValue
f FLOAT32
range ENUMERATED(Byte) MX dchg O
q BVstring13 MX qchg M
t Utctime MX M
configuration, description and extension
units Unit CF O
SIUnit Byte M
Multiplier Byte O
db INT32U CF O
dbAng INT32U CF O
zeroDb INT32U CF O
rangeC RangeConfig CF O
d Vstring255 DC O
CMV_1
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
measured attributes
instCVal FloatVector MX ------ O
mag FloatAnalogueValue
