B-48 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS
(845, 869, 889)
(845, 869, 889)
f FLOAT32
cVal FloatVector MX dchg M
mag FloatAnalogueValue
f FLOAT32
range ENUMERATED(Byte) MX dchg O
q BVstring13 MX qchg M
t Utctime MX M
configuration, description and extension
units Unit CF O
SIUnit Byte M
Multiplier Byte O
db INT32U CF O
dbAng INT32U CF O
zeroDb INT32U CF O
rangeC RangeConfig CF O
d Vstring255 DC O
dataNs Vstring255 EX M
CMV_2
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
measured attributes
cVal FloatVector MX dchg M
mag FloatAnalogueValue
f FLOAT32
q BVstring13 MX qchg M
t Utctime MX M
configuration, description and extension
units Unit CF O
SIUnit Byte M
Multiplier Byte O
d Vstring255 DC O
CMV_3
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
measured attributes
cVal FloatVector MX dchg M
mag FloatAnalogueValue
f FLOAT32
q BVstring13 MX qchg M
t Utctime MX M
configuration, description and extension
units Unit CF O
