B-60 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
PICS CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS
PICS
This section contains the Protocol Implementation Conformance Statement (PICS) for the
IEC 61850 interface in the 8 Series relays.
Version 1.0
Date: July 23, 2015
1 General
The following ACSI conformance statements are used to provide an overview and details
about 8 Series relays, with firmware 1.80:
• ACSI basic conformance statement,
• ACSI models conformance statement,
• ACSI service conformance statement
The statements specify the communication features mapped to IEC 61850-8-1 First Edition
and/or Edition 2.
2 ASCI basic conformance statement
The basic conformance statement is defined in Table B.1.
Table B.1: Basic conformance statement
Client/
Subscriber
Server/
Publisher
Value/
Comments
Client-Server roles
B11 Server side (of TWO-PARTY-
APPLICATION-ASSOCIATION)
Y
B12 Client side of (TWO-PARTY-
APPLICATION-ASSOCIATION)
SCSMs supported
B21 SCSM: IEC 6185-8-1 used Y
B22 SCSM: IEC 6185-9-1 used Ed2:
Deprecated
B23 SCSM: IEC 6185-9-2 used
B24 SCSM: other
Generic substation event model (GSE)
B31 Publisher side Y
B32 Subscriber side Y
Transmission of sampled value model (SVC)
B41 Publisher side
B42 Subscriber side
- = not applicable
Y = supported
N or empty = not supported
