2.1.3 LGOS (GOOSE subscription)
2.1.4 GoCB (GOOSE control block class definition)
2.2 Logical Nodes for protection functions. LN Group:P
2.2.1 PIOC (Instantaneous overcurrent)
phsPIOC: Phase IOC (845, 850, 889)
OfflinePIOC: Offline IOC (889)
LGOS class
Attribute Name Attr. Type Explanation M/O Notes
LGOS Logical node zero
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_2 Name plate M
St SPS_0 Status of the subscription M
LastStNum INS_0 Last state number
received
O
ConfRevNum INS_0 Expected conf revision
num.
O
GoCBRef ORG_0 O
GoCB class
Attribute Name Attribute Type FC Notes
GoEna BOOLEAN GO Enable (TRUE), disable (FALSE)
GoID VISIBLE STRING65 GO
DatSet Object Reference GO
ConfRev INT32U GO
NdsCom BOOLEAN GO
DstAddress PHYCOMADDR GO
PIOC class
Attribute Name Attr. Type Explanation M/O Notes
phsPIOC
Offline PIOC
Instantaneous
overcurrent
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_0 Start O
Op ACT_0 Operate M
