B-62 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
PICS CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS
4 ACSI service conformance statement
The ACSI service conformance statement is defined in Table B.3 (depending on the
statements in Table B.1).
Table B.3: ACSI service Conformance statement
If SVC (B41/B42) is supported
M14 Multicast SVC
M15 Unicast SVC
For all IEDs
M16 Time Y Y
Y = service is supported
N or empty = service is not supported
Client/
Subscriber
Server/
Publisher
Value/
Comments
Ed ACSI Service AA:
TP/MC
Client Sub
(C)
Server Pub
(S)
Comments
Server
S1 1,2 GetServerDirectory(LOGICAL-DEVICE) TP Y
Application association
S2 1,2 Associate TP Y
S3 1,2 Abort TP Y
S4 1,2 Release TP Y
Logical device
S5 1,2 GetLogicalDeviceDirectory TP Y
Logical node
S6 1,2 GetLogicalNodeDirectory TP Y
S7 1,2 GetAllDataValues TP Y
Data
S8 1,2 GetDataValues TP Y
S9 1,2 SetDataValues TP Y
S10 1,2 GetDataDirectory TP Y
S11 1,2 GetDataDefinition TP Y
Data set
S12 1,2 GetDataSetValues TP Y
S13 1,2 SetDataSetValues TP
S14 1,2 CreateDataSet TP
S15 1,2 DeleteDataSet TP
S16 1,2 GetDataSetDirectory TP Y
Substitution
S17 1 SetDataValues TP Ed1 only
