CHAPTER 7: IEC 60870-5-103 IEC 60870-5-103 MENUS
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 7-3
IEC 60870-5-103 Menus
PATH: SETPOINTS > DEVICE > COMMUNICATIONS > IEC103 POINT LISTS > BINARY INPUTS
BINARY INPUT POINT X
FUNC TYPE
Range: 0 to 255 in steps of 1
Default: 0
INFO NUM
Range: 0 to 255 in steps of 1
Default: 0
POINT X
Range: 0 to 255 in steps of 1
Default: 0
PRESENT IN GEN INTERROGATION
Range: YES, NO
Default: NO
Select YES to send the binary input in response to a general interrogation request. By
default, the binary input is not sent.
There are five measurand ASDUs available. The Fifth ASDU supports more metering values
as shown below.
PATH: SETPOINTS > DEVICE > COMMUNICATIONS > IEC103 POINT LISTS > MEASURANDS >
FIRST ASDU...FIFTH ASDU
IDENT TYPE
Range: 3, 9
Default: 3
First/Second/Third/Fourth ASDU:
If Ident Type=3 , 4 Measurands are sent to the master
If Ident Type=9, 4 Measurands are sent to the master
Fifth ASDU:
If Ident Type=3 , 4 Measurands are sent to the master
If Ident Type=9 , 16 Measurands are sent to the master
PATH: SETPOINTS > DEVICE > COMMUNICATIONS > IEC103 POINT LISTS > COMMANDS
The IEC 60870-5-103 Disturbance Recorder supports disturbance data transmission. For
full functionality, the 64 Digital Channels need to be configured according to the Digital
Inputs configured in the Transient Recorder.
PATH: SETPOINTS > DEVICE > COMMUNICATIONS > IEC103 DISTURBANCE RECORDER
DIGITAL CHANNEL 1...64
FUNC TYPE
Range: 0 to 255 in steps of 1
Default: 0
INFO NUM
Range: 0 to 255 in steps of 1
Default: 0
