GE Multilin 869 - Logical Nodes for Power Transformers. LN Group: y

B-38 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS
2.10 Logical Nodes for power transformers. LN Group: Y
2.10.1 YRTR (Power Transformer)
YPTR: Harmonic Derating (845)
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Loc SPS_0 Local operation M
OpCnt INS_0 Operation counter M
Controls
Pos DPC_0 Switch position M
BlkOpn SPC_1 Block opening M
BlkClr SPC_1 Block closing M
Status information
SwTyp ENS_7 Switch type M
YPTR class
Attribute Name Attr.
Type
Explanation M/O Notes
XfmrYPTR
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
W1HaDeratStr ACD_3 O
W1HaDeratOp ACT_3 O
W2HaDeratStr ACD_3 O
W2HaDeratOp ACT_3 O
W3HaDeratStr ACD_3 O
W3HaDeratOp ACT_3 O
LodLimRed SPS_2 O
Measured values
W1LodFact MV_3 O
W1AvPhCur MV_3 O
W1HaDerat MV_3 O
W2LodFact MV_3 O
W2AvPhCur MV_3 O
W2HaDerat MV_3 O
W3LodFact MV_3 O
W3AvPhCur MV_3 O
W3HaDerat MV_3 O
