CHAPTER 13: MODBUS MEMORY MAP
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 13-15
32078 0x081D Start Effective Current 0 2000 1 x FLA F2 0 1 Y
32079 0x081E Start Peak Current 0 2000 1 x FLA F2 0 1 Y
Learned Data
32090 0x0829 Records Since Clear 0 65535 1 F0 0 1 Y
32091 0x082A Last Clear Date/Time 0 0xFFFFFFFF 1 F50 0 2 Y
32093 0x082C Learned Acceleration
Time
0 250000 1 s F13 0 2 Y
32095 0x082E Learned Starting Current 0 2000 1 x FLA F2 0 1 Y
32096 0x082F Learned Start TCU 0 100 1 % F0 0 1 Y
32097 0x0830 Last Acceleration Time 0 250000 1 s F13 0 2 Y
32099 0x0832 Last Starting Current 0 2000 1 x FLA F2 0 1 Y
32100 0x0833 Last Start TCU 0 100 1 % F0 0 1 Y
32101 0x0834 Learned Average Load 0 2000 1 x FLA F2 0 1 Y
32102 0x0835 Learned Average kW -2147483648 2147483647 1 kW F31 0 2 Y
32104 0x0837 Learned Average kvar -2147483648 2147483647 1 kvar F31 0 2 Y
32106 0x0839 Learned Average PF -99 100 1 F22 0 1 Y
32123 0x084A Average Run Time (Days) 0 100000 1 days F10 0 2 Y
32125 0x084C Average Run Time (Hr/
Min)
0 0xFFFFFFFF 1 hr/min F55 0 2 Y
32177 0x0880 RTD Max 1 Temperature -41 251 1 °C F20E 1 Y
32178 0x0881 RTD Max 2 Temperature -41 251 1 °C F20E 1 Y
32179 0x0882 RTD Max 3 Temperature -41 251 1 °C F20E 1 Y
32180 0x0883 RTD Max 4 Temperature -41 251 1 °C F20E 1 Y
32181 0x0884 RTD Max 5 Temperature -41 251 1 °C F20E 1 Y
32182 0x0885 RTD Max 6 Temperature -41 251 1 °C F20E 1 Y
32183 0x0886 RTD Max 7 Temperature -41 251 1 °C F20E 1 Y
32184 0x0887 RTD Max 8 Temperature -41 251 1 °C F20E 1 Y
32185 0x0888 RTD Max 9 Temperature -41 251 1 °C F20E 1 Y
32186 0x0889 RTD Max 10 Temperature -41 251 1 °C F20E 1 Y
32187 0x088A RTD Max 11 Temperature -41 251 1 °C F20E 1 Y
32188 0x088B RTD Max 12 Temperature -41 251 1 °C F20E 1 Y
32189 0x088C RTD Max 13 Temperature -41 251 1 °C F20E 1 Y
Xfmr DFR Records
32220 0x08AB Records Since Clear 0 4000000000 1 F10 0 2 Y
32222 0x08AD Last Clear Date/Time 0 0xFFFFFFFF 1 F50 0 2 Y
Breaker 1 Arcing Current
32230 0x08B5 Arcing Current Phase A 0 4294967295 1 kA2-cyc F12 0 2 Y Y Y Y
32232 0x08B7 Arcing Current Phase B 0 4294967295 1 kA2-cyc F12 0 2 Y Y Y Y
32234 0x08B9 Arcing Current Phase C 0 4294967295 1 kA2-cyc F12 0 2 Y Y Y Y
32236 0x08BB Total Arcing Current 0 4294967295 1 kA2-cyc F12 0 2 Y Y Y Y
Breaker 2 Arcing Current
32238 0x08BD Arcing Current Phase A 0 4294967295 1 kA2-cyc F12 0 2 Y Y Y
32240 0x08BF Arcing Current Phase B 0 4294967295 1 kA2-cyc F12 0 2 Y Y Y
32242 0x08C1 Arcing Current Phase C 0 4294967295 1 kA2-cyc F12 0 2 Y Y Y
32244 0x08C3 Total Arcing Current 0 4294967295 1 kA2-cyc F12 0 2 Y Y Y
Breaker 3 Arcing Current
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
Words
8
5
0
8
6
9
8
8
9
8
4
5
