13-26 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
CHAPTER 13: MODBUS MEMORY MAP
33734 0x0E95 Ic Diff 2nd Harm 0 1000 1 % F1 0 1 Y
33735 0x0E96 Ia Diff 5th Harm 0 1000 1 % F1 0 1 Y
33736 0x0E97 Ib Diff 5th Harm 0 1000 1 % F1 0 1 Y
33737 0x0E98 Ic Diff 5th Harm 0 1000 1 % F1 0 1 Y
33738 0x0E99 Ia Diff 0 1000000 1 x CT F13 0 2 Y
33740 0x0E9B Ib Diff 0 1000000 1 x CT F13 0 2 Y
33742 0x0E9D Ic Diff 0 1000000 1 x CT F13 0 2 Y
33744 0x0E9F Ia Restr 0 1000000 1 x CT F13 0 2 Y
33746 0x0EA1 Ib Restr 0 1000000 1 x CT F13 0 2 Y
33748 0x0EA3 Ic Restr 0 1000000 1 x CT F13 0 2 Y
Overall Percent Differential Values
33772 0x0EBB Ia Diff 2nd Harm 0 1000 1 % F1 0 1 Y
33773 0x0EBC Ib Diff 2nd Harm 0 1000 1 % F1 0 1 Y
33774 0x0EBD Ic Diff 2nd Harm 0 1000 1 % F1 0 1 Y
33775 0x0EBE Ia Diff 5th Harm 0 1000 1 % F1 0 1 Y
33776 0x0EBF Ib Diff 5th Harm 0 1000 1 % F1 0 1 Y
33777 0x0EC0 Ic Diff 5th Harm 0 1000 1 % F1 0 1 Y
33778 0x0EC1 Ia Ovrl Diff 0 1000000 1 x CT F13 0 2 Y
33780 0x0EC3 Ib Ovrl Diff 0 1000000 1 x CT F13 0 2 Y
33782 0x0EC5 Ic Ovrl Diff 0 1000000 1 x CT F13 0 2 Y
33784 0x0EC7 Ia Ovrl Restr 0 1000000 1 x CT F13 0 2 Y
33786 0x0EC9 Ib Ovrl Restr 0 1000000 1 x CT F13 0 2 Y
33788 0x0ECB Ic Ovrl Restr 0 1000000 1 x CT F13 0 2 Y
Motor Thermal Model
33800 0x0ED7 Motor Load 0 4000 1 x FLA F2 0 1 Y
33801 0x0ED8 Current Unbalance 0 1000 1 % F1 0 1 Y
33802 0x0ED9 Therm Model Biased Load 0 4000 1 x FLA F2 0 1 Y
33803 0x0EDA Fltd Motor Load 0 4000 1 x FLA F2 0 1 Y
33804 0x0EDB Fltd RMS Cur A 0 120000000 1 A F13 0 2 Y
33806 0x0EDD Fltd RMS Cur B 0 120000000 1 A F13 0 2 Y
33808 0x0EDF Fltd RMS Cur C 0 120000000 1 A F13 0 2 Y
33810 0x0EE1 Fltd Mag Cur A 0 120000000 1 A F13 0 2 Y
33812 0x0EE3 Fltd Mag Cur B 0 120000000 1 A F13 0 2 Y
33814 0x0EE5 Fltd Mag Cur C 0 120000000 1 A F13 0 2 Y
Speed AV
33820 0x0EEB Speed 0 8640 1 RPM F0 0 1 Y Y
Broken Rotor Bar Values
33830 0x0EF5 Component Level -1000 0 1 dB F21 0 1 Y
33831 0x0EF6 Component Frequency 0 7600 1 Hz F2 0 1 Y
33832 0x0EF7 Motor load at BRB
Calculation
0 150 1 x FLA F2 0 1 Y
33833 0x0EF8 Load Dev. at BRB
Calculation
0 150 1 x FLA F2 0 1 Y
33834 0x0EF9 Time of BRB Calculation 0 0xFFFFFFFF 1 F50 0 2 Y
33836 0x0EFB Maximum Component
Level
-1000 0 1 dB F21 -10 1 Y
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
Words
8
5
0
8
6
9
8
8
9
8
4
5
