CHAPTER 13: MODBUS MEMORY MAP
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 13-29
34215 0x1076 %RH Hourly Average H
Limit
0 100 1 % F0 0 1 Y
34216 0x1077 %RH Hourly Average HH
Limit
0 100 1 % F0 0 1 Y
34217 0x1078 H2O ppm Level H Limit 0 0xFFFFFFFF 1 ppm F10 0 2 Y
34219 0x107A H2O ppm Level HH Limit 0 0xFFFFFFFF 1 ppm F10 0 2 Y
34221 0x107C H2O ppm Hourly Avg H
Limit
0 0xFFFFFFFF 1 ppm F10 0 2 Y
34223 0x107E H2O ppm Hourly Avg HH
Limit
0 0xFFFFFFFF 1 ppm F10 0 2 Y
Frequency OOB Accum
34270 0x10AD Freq OOB 1 Accum 0 9999 1 % F1 0 1 Y
34271 0x10AE Freq OOB 2 Accum 0 9999 1 % F1 0 1 Y
34272 0x10AF Freq OOB 3 Accum 0 9999 1 % F1 0 1 Y
34273 0x10B0 Freq OOB 4 Accum 0 9999 1 % F1 0 1 Y
34274 0x10B1 Freq OOB 5 Accum 0 9999 1 % F1 0 1 Y
34275 0x10B2 Freq OOB 6 Accum 0 9999 1 % F1 0 1 Y
34276 0x10B3 Freq OOB 7 Accum 0 9999 1 % F1 0 1 Y
Stat Gnd 3rd Harm
34310 0x10D5 3rd Harm VN in Sec 0 9999 0 V F2 0 1 Y
34311 0x10D6 3rd Harm V0 in Sec 0 9999 0 V F2 0 1 Y
34312 0x10D7 3rd Harm VN+V0 in Sec 0 9999 0 V F2 0 1 Y
Positive Impedance 1
34350 0x10FD Z1 Resistance -2147483647 2147483647 1 ohms F32 0 2 Y Y
34352 0x10FF Z1 Reactance -2147483647 2147483647 1 ohms F32 0 2 Y Y
34354 0x1101 Z1 Magnitude 0 2147483647 1 ohms F12 0 2 Y Y
34356 0x1103 Z1 Angle -3599 3599 1 ° F21 0 1 Y Y
Positive Impedance 2
34360 0x1107 Z1 Resistance -2147483647 2147483647 1 ohms F32 0 2 Y Y
34362 0x1109 Z1 Reactance -2147483647 2147483647 1 ohms F32 0 2 Y Y
34364 0x110B Z1 Magnitude 0 2147483647 1 ohms F12 0 2 Y Y
34366 0x110D Z1 Angle -3599 3599 1 ° F21 0 1 Y Y
Neutral Admittance 1 AV
34370 0x1111 Ntrl Admit Mag 0 23000000 1 mS F12 0 2 Y
34372 0x1113 Ntrl Admit Angle -3599 3599 1 ° F21 0 1 Y
34373 0x1114 Ntrl Conductance -23000000 23000000 1 mS F32 0 2 Y
34375 0x1116 Ntrl Susceptance -23000000 23000000 1 mS F32 0 2 Y
Neutral Admittance 2 AV
34377 0x1118 Ntrl Admit Mag 0 23000000 1 mS F12 0 2 Y
34379 0x111A Ntrl Admit Angle -3599 3599 1 ° F21 0 1 Y
34380 0x111B Ntrl Conductance -23000000 23000000 1 mS F32 0 2 Y
34382 0x111D Ntrl Susceptance -23000000 23000000 1 mS F32 0 2 Y
Neutral Admittance 3 AV
34384 0x111F Ntrl Admit Mag 0 23000000 1 mS F12 0 2 Y
34386 0x1121 Ntrl Admit Angle -3599 3599 1 ° F21 0 1 Y
34387 0x1122 Ntrl Conductance -23000000 23000000 1 mS F32 0 2 Y
34389 0x1124 Ntrl Susceptance -23000000 23000000 1 mS F32 0 2 Y
