CHAPTER 13: MODBUS MEMORY MAP
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 13-35
34869 0x1304 LEA2 V0 Angle -3599 0 1 ° F21 0 1 Y
34870 0x1305 LEA2 V1 Angle -3599 0 1 ° F21 0 1 Y
34871 0x1306 LEA2 V2 Angle -3599 0 1 ° F21 0 1 Y
Frequency Values 1
34891 0x131A Frequency 2000 90000 1 Hz F13 2000 2 Y Y Y Y
J Module Frequency
34930 0x1341 J1-CT Frequency 0 120000 1 Hz F13 0 2 Y Y Y Y
34932 0x1343 J1-CT Frq Rate of Chge -12000 12000 1 Hz/sec F22 0 1 Y Y Y Y
34933 0x1344 J2-3VT Frequency 0 120000 1 Hz F13 0 2 Y Y Y Y
34935 0x1346 J2-3VT Frq Rate of Chge -12000 12000 1 Hz/sec F22 0 1 Y Y Y Y
34936 0x1347 J2-Vx Frequency 0 120000 1 Hz F13 0 2 Y Y Y Y
34938 0x1349 J2-Vx Frq Rate of Chge -12000 12000 1 Hz/sec F22 0 1 Y Y Y Y
K Module Frequency
34942 0x134D K1-CT Frequency 0 120000 1 Hz F13 0 2 Y Y
34944 0x134F K1-CT Frq Rate of Chge -12000 12000 1 Hz/sec F22 0 1 Y Y
34945 0x1350 K2-3VT Frequency 0 120000 1 Hz F13 0 2 Y
34947 0x1352 K2-3VT Frq Rate of Chge -12000 12000 1 Hz/sec F22 0 1 Y
34948 0x1353 K2-Vx Frequency 0 120000 1 Hz F13 0 2 Y
34950 0x1355 K2-Vx Frq Rate of Chge -12000 12000 1 Hz/sec F22 0 1 Y
34951 0x1356 K2-CT Frequency 0 120000 1 Hz F13 0 2 Y Y
34953 0x1358 K2-CT Frq Rate of Chge -12000 12000 1 Hz/sec F22 0 1 Y Y
JK Module Frequency
34954 0x1359 JK-CT Frequency 0 120000 1 Hz F13 0 2 Y
34956 0x135B JK-CT Frq Rate of Chge -12000 12000 1 Hz/sec F22 0 1 Y
LEA Frequency - J
34970 0x1369 J2-LEA1 Frequency 0 120000 1 Hz F13 0 2 Y
34972 0x136B J2-LEA2 Frequency 0 120000 1 Hz F13 0 2 Y
34974 0x136D J2-LEA1 Frq Rate of Chge -12000 12000 1 Hz/sec F22 0 1 Y
34975 0x136E J2-LEA2 Frq Rate of Chge -12000 12000 1 Hz/sec F22 0 1 Y
Fast Underfrequency
34980 0x1373 Fast Frequency 2000 7000 1 Hz F2 6000 1 Y
34981 0x1374 Fast Rate of Change -12000 12000 1 Hz/sec F22 0 1 Y
Volts per Hertz
34990 0x137D Volts Per Hertz 1 0 400 1 V/Hz F2 100 1 Y Y Y
34991 0x137E Volts Per Hertz 2 0 400 1 V/Hz F2 100 1 Y Y
J1 Harmonic I Magnitude
35000 0x1387 J1 Phase A 2nd Harm
Mag
0 0xFFFFFFFF 1 A F13 0 2 Y Y Y
35002 0x1389 J1 Phase B 2nd Harm
Mag
0 0xFFFFFFFF 1 A F13 0 2 Y Y Y
35004 0x138B J1 Phase C 2nd Harm
Mag
0 0xFFFFFFFF 1 A F13 0 2 Y Y Y
35006 0x138D J1 Phase A 5th Harm Mag 0 0xFFFFFFFF 1 A F13 0 2 Y Y Y
35008 0x138F J1 Phase B 5th Harm Mag 0 0xFFFFFFFF 1 A F13 0 2 Y Y Y
35010 0x1391 J1 Phase C 5th Harm Mag 0 0xFFFFFFFF 1 A F13 0 2 Y Y Y
K1 Harmonic I Magnitude
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
Words
8
5
0
8
6
9
8
8
9
8
4
5
