CHAPTER 13: MODBUS MEMORY MAP
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 13-51
36230 0x1855 Pwr2 D/T Apparent
Demand
0 0xFFFFFFFF 1 F50 0 2 Y
36232 0x1857 Pwr2 Apparent Dmd
Time(us)
0 999999 1 us F51 0 2 Y
Power Demand Values 4
36244 0x1863 Pwr2 Reset Dmd Date/
Time
0 0xFFFFFFFF 1 F50 0 2 Y
36246 0x1865 Pwr2 Reset Dmd Time (us) 0 999999 1 us F51 0 2 Y
36248 0x1867 Pwr2 Real Dmd -2147483648 2147483647 1 kW F31 0 2 Y
36250 0x1869 Pwr2 Max Real Dmd -2147483648 2147483647 1 kW F31 0 2 Y
36252 0x186B Pwr2 Date/Time Real
Dmd
0 0xFFFFFFFF 1 F50 0 2 Y
36254 0x186D Pwr2 Real Dmd Time (us) 0 999999 1 us F51 0 2 Y
36256 0x186F Pwr2 Reactive Dmd -2147483648 2147483647 1 kvar F31 0 2 Y
36258 0x1871 Pwr2 Max Reactive Dmd -2147483648 2147483647 1 kvar F31 0 2 Y
36260 0x1873 Pwr2 D/T Reactive Dmd 0 0xFFFFFFFF 1 F50 0 2 Y
36262 0x1875 Pwr2 Reactive Dmd
Time(us)
0 999999 1 us F51 0 2 Y
36264 0x1877 Pwr2 Apparent Dmd -2147483648 2147483647 1 kVA F31 0 2 Y
36266 0x1879 Pwr2 Max Apparent Dmd -2147483648 2147483647 1 kVA F31 0 2 Y
36268 0x187B Pwr2 D/T Apparent
Demand
0 0xFFFFFFFF 1 F50 0 2 Y
36270 0x187D Pwr2 Apparent Dmd
Time(us)
0 999999 1 us F51 0 2 Y
Thermal Capacity
36290 0x1891 Phase A Thermal 1 Cap 0 65535 1 % F1 0 1 Y
36291 0x1892 Phase B Thermal 1 Cap 0 65535 1 % F1 0 1 Y
36292 0x1893 Phase C Thermal 1 Cap 0 65535 1 % F1 0 1 Y
36293 0x1894 Phase A Thermal 2 Cap 0 65535 1 % F1 0 1 Y
36294 0x1895 Phase B Thermal 2 Cap 0 65535 1 % F1 0 1 Y
36295 0x1896 Phase C Thermal 2 Cap 0 65535 1 % F1 0 1 Y
Directional Power
36310 0x18A5 Directional Power 1 -2147483648 2147483647 1 kW F31 0 2 Y Y Y Y
36312 0x18A7 Directional Power 2 -2147483648 2147483647 1 kW F31 0 2 Y Y Y Y
36314 0x18A9 Directional Power 3 -2147483648 2147483647 1 kW F31 0 2 Y
36316 0x18AB Directional Power 4 -2147483648 2147483647 1 kW F31 0 2 Y
Wattmetric Ground Fault
36330 0x18B9 Wattmetric Ground Fault
1
-2147483648 2147483647 1 W F32 0 2 Y
36332 0x18BB Wattmetric Ground Fault
2
-2147483648 2147483647 1 W F32 0 2 Y
36334 0x18BD Wattmetric Ground Fault
3
-2147483648 2147483647 1 W F32 0 2 Y
36336 0x18BF Wattmetric Ground Fault
4
-2147483648 2147483647 1 W F32 0 2 Y
CT Supervision 1 AV
36350 0x18CD CTS 1 Sym Imin 0 120000000 1 A F13 0 2 Y
36352 0x18CF CTS 1 Sym Imax 0 120000000 1 A F13 0 2 Y
36354 0x18D1 CTS 1 Sym Quotient 0 100 1 F2 0 1 Y
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
Words
8
5
0
8
6
9
8
8
9
8
4
5
To Next Page
