13-70 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
CHAPTER 13: MODBUS MEMORY MAP
38459 0x210A Element Status 560
(Breaker 1 Arcing Current)
0 65535 1 FC151 1 Y Y Y Y
38460 0x210B Element Status 561
(Breaker 2 Arcing Current)
0 65535 1 FC151 1 Y Y Y
38461 0x210C Element Status 562
(Breaker 3 Arcing Current)
0 65535 1 FC151 1 Y
38465 0x2110 Element Status 566
(Breaker1 Health)
0 65535 1 FC151 1 Y Y Y Y
38466 0x2111 Element Status 567
(Breaker2 Health)
0 65535 1 FC151 1 Y Y Y
38467 0x2112 Element Status 568
(Breaker3 Health)
0 65535 1 FC151 1 Y
38471 0x2116 Element Status 572
(Breaker1 Arc Health)
0 65535 1 FC151 1 Y Y Y Y
38472 0x2117 Element Status 573
(Breaker2 Arc Health)
0 65535 1 FC151 1 Y Y Y
38473 0x2118 Element Status 574
(Breaker3 Arc Health)
0 65535 1 FC151 1 Y
38477 0x211C Element Status 578
(Broken Rotor Bar)
0 65535 1 FC151 1 Y
38478 0x211D Element Status 579
(Stator Inter-Turn Fault)
0 65535 1 FC151 1 Y
38479 0x211E Element Status 580 (ESA
1)
0 65535 1 FC151 1 Y
38480 0x211F Element Status 581 (ESA
2)
0 65535 1 FC151 1 Y
38481 0x2120 Element Status 582
(Power Factor 1)
0 65535 1 FC151 1 Y Y
38482 0x2121 Element Status 583
(Power Factor 2)
0 65535 1 FC151 1 Y Y
38483 0x2122 Element Status 584
(Power Factor 3)
0 65535 1 FC151 1 Y
38484 0x2123 Element Status 585
(Power Factor 4)
0 65535 1 FC151 1 Y
38489 0x2128 Element Status 590
(Power Factor Trip (Motor
Generator))
0 65535 1 FC151 1 Y Y
38490 0x2129 Element Status 591
(Power Factor Alarm
(Motor Generator))
0 65535 1 FC151 1 Y Y
38491 0x212A Element Status 592
(Current Dmd 1)
0 65535 1 FC151 1 Y Y Y Y
38492 0x212B Element Status 593
(Current Dmd 2)
0 65535 1 FC151 1 Y Y
38493 0x212C Element Status 594
(Current Dmd 3)
0 65535 1 FC151 1 Y Y
38494 0x212D Element Status 595
(Current Dmd 4)
0 65535 1 FC151 1 Y
38495 0x212E Element Status 596 (Real
Power Demand 1)
0 65535 1 FC151 1 Y Y Y Y
38496 0x212F Element Status 597 (Real
Power Demand 2)
0 65535 1 FC151 1 Y
38497 0x2130 Element Status 598 (Real
Power Demand 3)
0 65535 1 FC151 1 Y
38498 0x2131 Element Status 599 (Real
Power Demand 4)
0 65535 1 FC151 1 Y
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
Words
8
5
0
8
6
9
8
8
9
8
4
5
