CHAPTER 13: MODBUS MEMORY MAP
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 13-77
38735 0x221E Element Status 836 (Arc
Flash Light Sensor
Trouble)
0 65535 1 FC151 1 Y Y Y Y
38736 0x221F Element Status 837 (Arc
Flash Light Sensor 1-4
Trouble)
0 65535 1 FC151 1 Y Y Y Y
38737 0x2220 Element Status 838 (Arc
Flash Light Sensor 5-8
Trouble)
0 65535 1 FC151 1 Y Y Y Y
38738 0x2221 Element Status 839
(Synchrocheck 1)
0 65535 1 FC151 1 Y Y Y
38739 0x2222 Element Status 840
(Synchrocheck 2)
0 65535 1 FC151 1 Y
38742 0x2225 Element Status 843
(Manual Close Blocking
BKR1)
0 65535 1 FC151 1 Y
38743 0x2226 Element Status 844
(Manual Close Blocking
BKR2)
0 65535 1 FC151 1 Y
38744 0x2227 Element Status 845 (Cold
Load Pickup 1)
0 65535 1 FC151 1 Y
38745 0x2228 Element Status 846 (Cold
Load Pickup 2)
0 65535 1 FC151 1 Y
38747 0x222A Element Status 848
(Undervoltage
Restoration 1)
0 65535 1 FC151 1 Y
38748 0x222B Element Status 849
(Undervoltage
Restoration 2)
0 65535 1 FC151 1 Y
38749 0x222C Element Status 850
(Underfrequency
Restoration 1)
0 65535 1 FC151 1 Y
38750 0x222D Element Status 851
(Underfrequency
Restoration 2)
0 65535 1 FC151 1 Y
38751 0x222E Element Status 852 (Bus
Transfer)
0 65535 1 FC151 1 Y
38752 0x222F Element Status 853
(Transfer Initiated)
0 65535 1 FC151 1 Y
38753 0x2230 Element Status 854
(AutoReclose 1)
0 65535 1 FC151 1 Y
38754 0x2231 Element Status 855 (AR1
Shot Cnt)
0 65535 1 FC151 1 Y
38755 0x2232 Element Status 856 (AR1
Shot Cnt Reduction)
0 65535 1 FC151 1 Y
38756 0x2233 Element Status 857 (AR1
Rate Supervision)
0 65535 1 FC151 1 Y
38757 0x2234 Element Status 858
(AutoReclose 2)
0 65535 1 FC151 1 Y
38758 0x2235 Element Status 859 (AR2
Shot Cnt)
0 65535 1 FC151 1 Y
38759 0x2236 Element Status 860 (AR2
Shot Cnt Reduction)
0 65535 1 FC151 1 Y
38760 0x2237 Element Status 861 (AR2
Rate Supervision)
0 65535 1 FC151 1 Y
38765 0x223C Element Status 866 (CT
Supervision 1)
0 65535 1 FC151 1 Y
