40774 0x0305 DGA History 0 0xC6CD00 1 FC142 0 2 Y
40776 0x0307 Running Hours 0 0xC6CD00 1 FC142 0 2 Y
40778 0x0309 Stator Inter-Turn Fault 0 0xC6CD00 1 FC142 0 2 Y Y
40780 0x030B ESA Baseline Data 0 0xC6CD00 1 FC142 0 2 Y
40782 0x030D ESA Operational Data 0 0xC6CD00 1 FC142 0 2 Y
40784 0x030F Last Trip Data 0 0xC6CD00 1 FC142 0 2 Y Y Y Y
Contact Input Voltage Threshold
41000 0x03E7 Voltage Threshold / Slot F 0 3 1 FC123 1 1 Y Y Y Y
41001 0x03E8 Voltage Threshold / Slot G 0 3 1 FC123 1 1 Y Y Y Y
41002 0x03E9 Voltage Threshold / Slot H 0 3 1 FC123 1 1 Y Y Y Y
41003 0x03EA Voltage Threshold /F13-
F17
0 3 1 FC123 1 1 YYYY
41004 0x03EB Voltage Threshold /F19-
F23
0 3 1 FC123 1 1 YYYY
41005 0x03EC Voltage Threshold /F11/
F13
0 3 1 FC123 1 1 YYYY
41006 0x03ED Voltage Threshold /F15-
18/F20-F23
0 3 1 FC123 1 1 YYYY
41007 0x03EE Voltage Threshold /G13-
G17
0 3 1 FC123 1 1 YYYY
41008 0x03EF Voltage Threshold /G19-
G23
0 3 1 FC123 1 1 YYYY
41009 0x03F0 Voltage Threshold /G11/
G13
0 3 1 FC123 1 1 YYYY
41010 0x03F1 Voltage Threshold /G15-
18/G20-G23
0 3 1 FC123 1 1 YYYY
41011 0x03F2 Voltage Threshold /H13-
H17
0 3 1 FC123 1 1 YYYY
41012 0x03F3 Voltage Threshold /H19-
H23
0 3 1 FC123 1 1 YYYY
41013 0x03F4 Voltage Threshold /H11/
H13
0 3 1 FC123 1 1 YYYY
41014 0x03F5 Voltage Threshold /H15-
18/H20-H23
0 3 1 FC123 1 1 YYYY
41015 0x03F6 Voltage Threshold /B1-B5 0 3 1 FC123 1 1 Y Y Y Y
41016 0x03F7 Voltage Threshold /B7-
B11
0 3 1 FC123 1 1 YYYY
41017 0x03F8 Voltage Threshold /B13-
B17
0 3 1 FC123 1 1 YYYY
41018 0x03F9 Voltage Threshold /C1-C5 0 3 1 FC123 1 1 Y Y Y Y
41019 0x03FA Voltage Threshold /C7-
C11
0 3 1 FC123 1 1 YYYY
41020 0x03FB Voltage Threshold /C13-
C17
0 3 1 FC123 1 1 YYYY
Contact Input 1
41030 0x0405 Name 0 65535 1 F60_26 CI 1 13 Y Y Y Y
41043 0x0412 Debounce Time 0 160 5 ms F1 100 1 Y Y Y Y
41044 0x0413 Events 0 1 1 FC126 1 1 Y Y Y Y
Contact Input 2
41045 0x0414 Name 0 65535 1 F60_26 CI 2 13 Y Y Y Y
41058 0x0421 Debounce Time 0 160 5 ms F1 100 1 Y Y Y Y
