13-130 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
CHAPTER 13: MODBUS MEMORY MAP
51506 0x2CF1 PRT5 Subnet IP Mask 0 0xFFFFFFFF 1 F70 0 2 Y Y Y Y
Default Route
51530 0x2D09 Gateway Address 1 0xDFFFFFFE 1 F70 0x7F0000
01
2YYYY
Static RT 1
51532 0x2D0B RT1 Destination 1 0xDFFFFFFE 1 F70 0x7F0000
01
2YYYY
51534 0x2D0D RT1 Mask 0 0xFFFFFFFF 1 F70 0xFF0000
00
2YYYY
51536 0x2D0F RT1 Gateway 1 0xDFFFFFFE 1 F70 0x7F0000
01
2YYYY
Static RT 2
51538 0x2D11 RT2 Destination 1 0xDFFFFFFE 1 F70 0x7F0000
01
2YYYY
51540 0x2D13 RT2 Mask 0 0xFFFFFFFF 1 F70 0xFF0000
00
2YYYY
51542 0x2D15 RT2 Gateway 1 0xDFFFFFFE 1 F70 0x7F0000
01
2YYYY
Static RT 3
51544 0x2D17 RT3 Destination 1 0xDFFFFFFE 1 F70 0x7F0000
01
2YYYY
51546 0x2D19 RT3 Mask 0 0xFFFFFFFF 1 F70 0xFF0000
00
2YYYY
51548 0x2D1B RT3 Gateway 1 0xDFFFFFFE 1 F70 0x7F0000
01
2YYYY
Static RT 4
51550 0x2D1D RT4 Destination 1 0xDFFFFFFE 1 F70 0x7F0000
01
2YYYY
51552 0x2D1F RT4 Mask 0 0xFFFFFFFF 1 F70 0xFF0000
00
2YYYY
51554 0x2D21 RT4 Gateway 1 0xDFFFFFFE 1 F70 0x7F0000
01
2YYYY
Static RT 5
51556 0x2D23 RT5 Destination 1 0xDFFFFFFE 1 F70 0x7F0000
01
2YYYY
51558 0x2D25 RT5 Mask 0 0xFFFFFFFF 1 F70 0xFF0000
00
2YYYY
51560 0x2D27 RT5 Gateway 1 0xDFFFFFFE 1 F70 0x7F0000
01
2YYYY
Static RT 6
51562 0x2D29 RT6 Destination 1 0xDFFFFFFE 1 F70 0x7F0000
01
2YYYY
51564 0x2D2B RT6 Mask 0 0xFFFFFFFF 1 F70 0xFF0000
00
2YYYY
51566 0x2D2D RT6 Gateway 1 0xDFFFFFFE 1 F70 0x7F0000
01
2YYYY
DNP Protocol
51570 0x2D31 DNP Channel 1 Port 0 2 1 FC239 0 1 Y Y Y Y
51571 0x2D32 DNP Channel 2 Port 0 2 1 FC239 0 1 Y Y Y Y
51572 0x2D33 DNP Address 0 65519 1 F0 65519 1 Y Y Y Y
51573 0x2D34 DNP Client Address 1 0 0xFFFFFFFF 1 F70 0 2 Y Y Y Y
51575 0x2D36 DNP Client Address 2 0 0xFFFFFFFF 1 F70 0 2 Y Y Y Y
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
Words
