CHAPTER 13: MODBUS MEMORY MAP
56894 0x41FD Function 0 2 1 FC101 2 1 Y Y Y Y
56895 0x41FE ID Text 0 65535 1 F60_26 GndTrip
Enbld
13 YYYY
56908 0x420B ON Text 0 65535 1 F60_26 PB4 On 13 Y Y Y Y
56921 0x4218 OFF Text 0 65535 1 F60_26 PB4 Off 13 Y Y Y Y
56934 0x4225 Hold Pressed 0 100 1 s F1 1 1 Y Y Y Y
56935 0x4226 Autoreset 0 1 1 FC126 0 1 Y Y Y Y
56936 0x4227 Autoreset Delay 2 6000 1 s F1 10 1 Y Y Y Y
56937 0x4228 Lock 0 0xC6CD00 1 FC142 0 2 Y Y Y Y
56939 0x422A Dropout Time 0 6000 1 s F1 0 1 Y Y Y Y
56940 0x422B Events 0 1 1 FC126 1 1 Y Y Y Y
Programmable Pushbutton 5
56942 0x422D Function 0 2 1 FC101 2 1 Y
56943 0x422E ID Text 0 65535 1 F60_26 Remote
Enbld
13 Y
56956 0x423B ON Text 0 65535 1 F60_26 PB5 On 13 Y
56969 0x4248 OFF Text 0 65535 1 F60_26 PB5 Off 13 Y
56982 0x4255 Hold Pressed 0 100 1 s F1 1 1 Y
56983 0x4256 Autoreset 0 1 1 FC126 0 1 Y
56984 0x4257 Autoreset Delay 2 6000 1 s F1 10 1 Y
56985 0x4258 Lock 0 0xC6CD00 1 FC142 0 2 Y
56987 0x425A Dropout Time 0 6000 1 s F1 0 1 Y
56988 0x425B Events 0 1 1 FC126 1 1 Y
Programmable Pushbutton 6
56990 0x425D Function 0 2 1 FC101 2 1 Y
56991 0x425E ID Text 0 65535 1 F60_26 Hot Line
Tag
13 Y
57004 0x426B ON Text 0 65535 1 F60_26 PB6 On 13 Y
57017 0x4278 OFF Text 0 65535 1 F60_26 PB6 Off 13 Y
57030 0x4285 Hold Pressed 0 100 1 s F1 1 1 Y
57031 0x4286 Autoreset 0 1 1 FC126 0 1 Y
57032 0x4287 Autoreset Delay 2 6000 1 s F1 10 1 Y
57033 0x4288 Lock 0 0xC6CD00 1 FC142 0 2 Y
57035 0x428A Dropout Time 0 6000 1 s F1 0 1 Y
57036 0x428B Events 0 1 1 FC126 1 1 Y
Programmable Pushbutton 7
57038 0x428D Function 0 2 1 FC101 1 1 Y
57039 0x428E ID Text 0 65535 1 F60_26 Demand
Reset
13 Y
57052 0x429B ON Text 0 65535 1 F60_26 PB7 On 13 Y
57065 0x42A8 OFF Text 0 65535 1 F60_26 PB7 Off 13 Y
57078 0x42B5 Hold Pressed 0 100 1 s F1 1 1 Y
57079 0x42B6 Autoreset 0 1 1 FC126 0 1 Y
57080 0x42B7 Autoreset Delay 2 6000 1 s F1 10 1 Y
57081 0x42B8 Lock 0 0xC6CD00 1 FC142 0 2 Y
57083 0x42BA Dropout Time 0 6000 1 s F1 0 1 Y
57084 0x42BB Events 0 1 1 FC126 1 1 Y
Modbus
Address
Hex
Address
Description Min Max Step Units Format
Code
Factory
Default
Size in
Words
8
5
0
8
6
9
8
8
9
8
4
5
To Next Page
