CHAPTER 6: IEC 60870-5-104 INTEROPERABILITY
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 6-7
FAST PATH:
“*” blank or X only
Basic application functions:
Station initialization:
⊠ Remote initialization.
Cyclic data transmission:
⊠ Cyclic data transmission.
Read procedure:
⊠ Read procedure.
Spontaneous transmission:
⊠ Spontaneous transmission.
Double transmission of information objects with cause of transmission spontaneous:
The following type identifications may be transmitted in succession caused by a single
status change of an information object. The particular information object addresses for
which double transmission is enabled are defined in a project-specific list.
□ Single point information: M_SP_NA_1, M_SP_TA_1, M_SP_TB_1, and M_PS_NA_1.
□ Double point information: M_DP_NA_1, M_DP_TA_1, and M_DP_TB_1.
□ Step position information: M_ST_NA_1, M_ST_TA_1, and M_ST_TB_1.
□ Bitstring of 32 bits: M_BO_NA_1, M_BO_TA_1, and M_BO_TB_1 (if defined for a specific
project).
□ Measured value, normalized value: M_ME_NA_1, M_ME_TA_1, M_ME_ND_1, and
M_ME_TD_1.
□ Measured value, scaled value: M_ME_NB_1, M_ME_TB_1, and M_ME_TE_1.
□ Measured value, short floating point number: M_ME_NC_1, M_ME_TC_1, and
M_ME_TF_1.
Station interrogation:
⊠ Group 1.
⊠ Group 2.
⊠ Group 3.
⊠ Group 4.
⊠ Group 5.
⊠ Group 6.
⊠ Group 7.
⊠ Group 8.
⊠ Group 9.
⊠ Group 10.
⊠ Group 11.
⊠ Group 12.
<121> F_SR_NA_1 ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░
<122> F_SC_NA_1 ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░
<123> F_LS_NA_1 ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░
<124> F_AF_NA_1 ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░
<125> F_SG_NA_1 ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░
<126> F_DR_TA_1*) ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░
<127> F_SC_NB_1*) ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░ ░
Type identification Cause of transmission
No. Mnemonic 1234567891011121320
to
36
37
to
41
44 45 46 47
