CHAPTER 8: IEC 61850 THE IEC 61850 CONFIGURATOR
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE 8-11
See the following list of supported parameters for the 8 Series relay. Note that the
same list is also supported for the MSQI logical node. MSQI parameters are displayed
only if the relay supports sensitive ground CT.
TotPF max = 1
min = -1
Hz max = 90
min = 0
HzRte max = 15
min = -15
PPV max = Phase VT Ratio * 240
min = 0
PhV max = Phase VT Ratio * 240
min = 0
A$phsA, phsB, phsC max = (Phase CT Primary * 46)
min = 0
A$neut max = (Ground CT Primary * 46)
min = 0
A$net max = (Phase CT Primary * 46)
min = 0
A$res max = (Sens. Ground CT Primary * 3)
min = 0
AuxV max = Aux. VT Ratio * 240
min = 0
SeqA$c1, c2 ,c3 max = (Phase CT Primary * 46)
min = 0
SeqV$c1, c2, c3 max = (Phase VT Ratio * 240)
min = 0
dbAng angle dB = (DB percentage* 360)
Supported Parameters (names begin with 845, 850, 869, or 889 depending on the specific relay)
850.MMXU1$CF$TotW$db
850.MMXU1$CF$TotVAr$db
850.MMXU1$CF$TotVA$db
850.MMXU1$CF$TotPF$db
850.MMXU1$CF$Hz$db
850.MMXU1$CF$Hz3VT$db
850.MMXU1$CF$HzVx$db
850.MMXU1$CF$PPV$phsAB$db
850.MMXU1$CF$PPV$phsAB$dbAng
850.MMXU1$CF$PPV$phsBC$db
850.MMXU1$CF$PPV$phsBC$dbAng
850.MMXU1$CF$PPV$phsCA$db
850.MMXU1$CF$PPV$phsCA$dbAng
850.MMXU1$CF$PhV$phsA$db
850.MMXU1$CF$PhV$phsA$dbAng
850.MMXU1$CF$PhV$phsB$db
850.MMXU1$CF$PhV$phsB$dbAng
850.MMXU1$CF$PhV$phsC$db
850.MMXU1$CF$PhV$phsC$dbAng
850.MMXU1$CF$PhV$neut$db
850.MMXU1$CF$PhV$neut$dbAng
MMXU Node Value To Calculate
