14-250 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
CHAPTER 14: FORMAT CODES
33812 Fltd Mag Cur B Y
33814 Fltd Mag Cur C Y
33820 Speed Y Y
33850 Operating Quantity Y
33851 Learned Unbal Z Y
33950 SC RMS Ia Y
33952 SC RMS Ib Y
33954 SC RMS Ic Y
33960 W1 Load (% of rated) Y
33961 W1 Average Ph Current Y
33963 W1 Harm Derate Factor Y
33972 W2 Load (% of rated) Y
33973 W2 Average Ph Current Y
33975 W2 Harm Derate Factor Y
33984 W3 Load (% of rated) Y
33985 W3 Average Ph Current Y
33987 W3 Harm Derate Factor Y
34040 Wndg Hottest Spot °C Y
34041 Aging Factor Y
34042 Daily Rate LOL Y
34044 Transformer Life Lost Y
34046 Top Oil Temperature Y
34047 Ambient Temperature Y
34060 Tap Position Y
34147 Hydran (H2) Y
34152 H2O ppm Level Y
34310 3rd Harm VN in Sec Y
34311 3rd Harm V0 in Sec Y
34312 3rd Harm VN+V0 in Sec Y
34350 PosImp1 Z1 Resistance Y Y
34352 PosImp1 Z1 Reactance Y Y
34354 PosImp1 Z1 Magnitude Y Y
34356 PosImp1 Z1 Angle Y Y
34360 PosImp2 Z1 Resistance Y Y
34362 PosImp2 Z1 Reactance Y Y
34364 PosImp2 Z1 Magnitude Y Y
34366 PosImp2 Z1 Angle Y Y
34370 Ntrl Admit 1 Mag Y
34372 Ntrl Admit 1 Angle Y
34373 Ntrl 1 Conductance Y
34375 Ntrl 1 Susceptance Y
34377 Ntrl Admit 2 Mag Y
34379 Ntrl Admit 2 Angle Y
34380 Ntrl 2 Conductance Y
34382 Ntrl 2 Susceptance Y
34384 Ntrl Admit 3 Mag Y
Code Type Definition 850 869 889 845
F0 unsigned 16 bits Unsigned Value
