B-10 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS
2.2.5 PTOV (Overvoltage)
phsPTOV: Phase overvoltage (845/850/889)
auxPTOV: Auxiliary overvoltage (845/850/889)
ndPTOV: Neutral overvoltage (845/850)
ngseqPTOV: negative sequence overvoltage (850/869/889)
phsrevPTOV: Phase reversal overvoltage (869)
2.2.6 PTUV (Undervoltage)
phsPTUV: Phase undervoltage
Status Information
Str ACD_2 Start M PTOF PKP
Op ACT_2 Operate M PTOF OP
PTOV class
Attribute Name Attr. Type Explanation M/O Notes
phsPTOV Overvoltage
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_0 Start M Phase TOV PKP
Op ACT_0 Operate O Phase TOV OP
PTOV class
Attribute Name Attr. Type Explanation M/O Notes
auxPTOV/
ndPTOV/
ngseqPTOV/
phsrevPTOV
Overvoltage
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_2 Start M
Op ACT_2 Operate M
PTUV class
Attribute Name Attr. Type Explanation M/O Notes
phsPTUV Undervoltage
Data
Common Logical Node Information
