B-36 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS
KxMSQI1: Sequence and imbalance (845-Slot K, 889-Slot K)
2.7.3 MMTR
MMTR: Metering
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Measured values
SeqA SEQ_0 Pos, Neg and Zero seq
Current
C I0_P, I1_P, I2_P
SeqV SEQ_0 Pos, Neg and Zero seq
Voltage
C V0_P, V1_P, V2_P
MSQI class
Attribute Name Attr.
Type
Explanation M/O/C Notes
MSQI_2 Sequence and imbalance
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Measured values
SeqA SEQ_0 Pos, Neg and Zero seq
Current
C I0_P, I1_P, I2_P
MMTR class
Attribute Name Attr.
Type
Explanation M/O Notes
MMTR_1 Metering
Data
Common Logical Node Information
Mod ENC_0 Mode M
Beh ENS_0 Behavior M
Health ENS_1 Health M
NamPlt LPL_1 Name plate M
Measured values
CntPsWh MV_1 Power Pos. WattHours O
CntNgWh MV_1 Power Neg. WattHours O
CntPsVArh MV_1 Power Pos. VArHours O
CntNgVArh MV_1 Power Neg. VArHours O
