CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS MICS
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE B-53
3.3.2 Controllable double point (DPC)
3.3.3 Controllable integer status (INC)
ctlModel ENUMERATED CF ctlModel_1 M
operTimeout INT32U CF AC_CO_O
d Vstring255 DC O
DPC_0
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
Oper ctlVal Boolean CO AC_CO_M
origin Originator CO,ST AC_CO_M
orCat ENUMERATED M
orIdent OCTECT64 M
ctlNum INT8U CO,ST M
T Btime6 CO M
Test Boolean CO M
Check ENUMERATED CO M
Cancel
SBO
SBOw
stVal CODE ENUM ST dchg intermediate-state | off | on
| bad-state
M
q BVstring13 ST qchg AC_ST
t Utctime ST AC_ST
configuration, description and extension
ctlModel ENUMERATED CF M
sboTimeout INT32U CF AC_CO_O
sboClass ENUMERATED CF AC_CO_O
operTimeout INT32U CF AC_CO_O
d Vstring255 DC O
INC_0
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
status
stVal Enum ST dcgh On, blocked, test, test/
blocked, Off
M
q BVstring13 ST qchg M
t Utctime ST M
configuration, description and extension
ctlModel ENUMERATED CF M
