CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS TICS TEMPLATE FOR SERVER
8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE B-57
Part 7-1
Tissue
Description Implemented
Y/na
828 Data model namespace revision IEC 61850-7-4:2007[A] Y
1151 simulated GOOSE disappears after 1st appearance when
LPHD.Sim = TRUE
na
1196 Extensions to standardized LN classes made by third
parties
na
Part 7-2
Tissue
Description Implemented
Y/na
778 AddCause values – add value not-supported Y
780 What are unsupported trigger option at a control block? Y
783 TimOper Resp- ; add Authorization check na
786 AddCause values 26 and 27 are switched Y
820 Mandatory ACSI services (use for PICS template) na
858 typo in enumeration ServiceType na
861 dchg of ConfRev attribute na
876 GenLogiclNodeClass and SGCB, GoCB, MsvCB, UsvCB na
1038 Loss of Info Detection After Resynch na
1050 GTS Phycomaddr definition in SCL na
1062 Entrytime not used in CDC na
1071 Length of DO name Y
1091 The sentence "The initial value of EditSG shall be 0", has to
be stated in part 7.2 not in 8.1
na
1127 Missing owner attribute in BTS and UTS na
1163 Old report in URCB na
1202 GI not optional Y
Part 7-3
Tissue
Description Implemented
Y/na
697 persistent command / PulseConfig na
698 Wrong case is BAC.dB attribute na
722 Units for 'h' and 'min' not in UnitKind enumeration. na
919 Presence Condition for sVC na
925 Presence of i or f attribute - Problem with writing na
926 Presence Conditions within RangeConfig Y
