B-64 8 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
PICS CHAPTER B: IEC 61850 IMPLEMENTATION DETAILS
S39 1,2 SetGoCBValues TP Y
GSSE (Ed2:61850-7-2 Annex C)
S40 1,2 SendGSSEMessage MC Deprecated
GSSE Control Block (Ed2:61850-7-2 Annex C)
S41 1,2 GetGsReference TP Deprecated
S42 1,2 GetGSSEDataOffset TP Deprecated
S43 1,2 Ge t Gs CB V a l u e s TP Deprecated
S44 1,2 SetGsCBValues TP Deprecated
Transmission of sampled value model (SVC)
Multicast SV
S45 1,2 SendMSVMessage MC Use for 9-2LE or IEC 61869-9
Multicast Sampled Value Control Block
S46 1,2 Ge t M S V C B V a l u e s TP
S47 1,2 SetMSVCBValues TP
Unicast SV
S48 1,2 SendUSVMessage TP
Unicast Sampled Value Control Block
S49 1,2 Ge t U S V C B V a l u e s TP
S50 1,2 SetUSVCBValues TP
Control
S51 1,2 Select TP Y SBO Normal Security
S52 1,2 SelectWithValue TP Y SBO Enhanced Security
S53 1,2 Cancel TP Y
S54 1,2 Operate TP Y
S55 1,2 CommandTermination TP Y
S56 1,2 TimeActivatedOperate TP
File transfer
S57 1,2 Ge t F i l e TP Y
S58 1,2 SetFile TP
S59 1,2 DeleteFile TP
S60 1,2 GetFileAttributeValues TP
S61 1,2 GetServerDirectory (FILE) TP Y
Time
T1 1,2 Time resolution of internal clock - 2 ms nearest negative power of 2 in seconds
T2 2 Time accuracy of internal clock - TL (ms) (low accuracy), T3 < 7) (only Ed2)
1,2 - T0 (ms) (<= 10 ms), 7 <= T3 < 10)
1,2 - T1 (µs) (<= 1 ms), 10 <= T3 < 13
1,2 - T2 (µs) (<= 100 µs), 13 <= T3 < 15
1,2 - T3 (µs) (<= 25 µs), 15 <= T3 < 18
1,2 - T4 (µs) (<= 4 µs), 18 <= T3 < 20
1,2 - T5 (µs) (<= 1 µs), T3 >= 20)
T3 1,2 Supported TimeStamp resolution - 1 µs nearest negative power of 2 in seconds
Ed ACSI Service AA:
TP/MC
Client Sub
(C)
Server Pub
(S)
Comments
