GE Multilin F35 Multiple Feeder Protection System 5-85
5 SETTINGS 5.4 FLEXLOGIC™
5
The operands available for this relay are listed alphabetically by types in the following table.
Table 5–7: F35 FLEXLOGIC™ OPERANDS (Sheet 1 of 6)
OPERAND TYPE OPERAND SYNTAX OPERAND DESCRIPTION
CONTROL
PUSHBUTTONS
CONTROL PUSHBTN 1 ON
CONTROL PUSHBTN 2 ON
CONTROL PUSHBTN 3 ON
CONTROL PUSHBTN 4 ON
CONTROL PUSHBTN 5 ON
CONTROL PUSHBTN 6 ON
CONTROL PUSHBTN 7 ON
Control pushbutton 1 is being pressed
Control pushbutton 2 is being pressed
Control pushbutton 3 is being pressed
Control pushbutton 4 is being pressed
Control pushbutton 5 is being pressed
Control pushbutton 6 is being pressed
Control pushbutton 7 is being pressed
DIRECT DEVICES DIRECT DEVICE 1On
↓
DIRECT DEVICE 16On
DIRECT DEVICE 1Off
↓
DIRECT DEVICE 16Off
Flag is set, logic=1
↓
Flag is set, logic=1
Flag is set, logic=1
↓
Flag is set, logic=1
DIRECT INPUT/
OUTPUT
CHANNEL
MONITORING
DIR IO CH1 CRC ALARM
DIR IO CH2 CRC ALARM
DIR IO CRC ALARM
DIR IO CH1 UNRET ALM
DIR IO CH2 UNRET ALM
DIR IO UNRET ALM
The rate of direct input messages received on channel 1 and failing the CRC
exceeded the user-specified level.
The rate of direct input messages received on channel 2 and failing the CRC
exceeded the user-specified level.
The rate of direct input messages failing the CRC exceeded the user-
specified level on channel 1 or 2.
The rate of returned direct input/output messages on channel 1 exceeded the
user-specified level (ring configurations only).
The rate of returned direct input/output messages on channel 2 exceeded the
user-specified level (ring configurations only).
The rate of returned direct input/output messages exceeded the user-
specified level on channel 1 or 2 (ring configurations only).
ELEMENT:
Eight-bit switch
8BIT SWITCH 1 BIT 0
8BIT SWITCH 1 BIT 1
8BIT SWITCH 1 BIT 2
8BIT SWITCH 1 BIT 3
8BIT SWITCH 1 BIT 4
8BIT SWITCH 1 BIT 5
8BIT SWITCH 1 BIT 6
8BIT SWITCH 1 BIT 7
Bit 0 of eight-bit switch 1 asserted (the least significant bit)
Bit 1 of eight-bit switch 1 asserted
Bit 2 of eight-bit switch 1 asserted
Bit 3 of eight-bit switch 1 asserted
Bit 4 of eight-bit switch 1 asserted
Bit 5 of eight-bit switch 1 asserted
Bit 6 of eight-bit switch 1 asserted
Bit 7 of eight-bit switch 1 asserted (the most significant bit)
8BIT SWITCH 2 to 8BIT
SWITCH 6
Same set of operands as shown for 8 BIT SWITCH 1 above
ELEMENT:
Autoreclose
(per CT bank)
AR1 ENABLED
AR1 RIP
AR1 LO
AR1 BLK FROM MAN CLS
AR1 CLOSE
AR1 SHOT CNT=0
AR1 SHOT CNT=1
AR1 SHOT CNT=2
AR1 SHOT CNT=3
AR1 SHOT CNT=4
AR1 DISABLED
Autoreclose 1 is enabled
Autoreclose 1 is in progress
Autoreclose 1 is locked out
Autoreclose 1 is temporarily disabled
Autoreclose 1 close command is issued
Autoreclose 1 shot count is 0
Autoreclose 1 shot count is 1
Autoreclose 1 shot count is 2
Autoreclose 1 shot count is 3
Autoreclose 1 shot count is 4
Autoreclose 1 is disabled
AR 2 to AR3 Same set of operands as shown for AR 1
ELEMENT:
Auxiliary
overvoltage
AUX OV1 PKP
AUX OV1 DPO
AUX OV1 OP
Auxiliary overvoltage element has picked up
Auxiliary overvoltage element has dropped out
Auxiliary overvoltage element has operated
AUX OV2 to AUX OV3 Same set of operands as shown for AUX OV1
ELEMENT:
Auxiliary
undervoltage
AUX UV1 PKP
AUX UV1 DPO
AUX UV1 OP
Auxiliary undervoltage element has picked up
Auxiliary undervoltage element has dropped out
Auxiliary undervoltage element has operated
AUX UV2 to AUX UV3 Same set of operands as shown for AUX UV1
ELEMENT:
Breaker arcing
BKR ARC 1 OP
BKR ARC 2 OP
Breaker arcing current 1 has operated
Breaker arcing current 2 has operated
