6.2.14 DIRECT DEVICES STATUS
PATH: ACTUAL VALUES Ö STATUS ÖØ DIRECT DEVICES STATUS
These actual values represent the state of direct devices 1 through 16.
6.2.15 EGD PROTOCOL STATUS
a) FAST EXCHANGE
PATH: ACTUAL VALUES Ö STATUS ÖØ EGD PROTOCOL STATUS Ö PRODUCER STATUS Ö FAST EXCHANGE 1
These values provide information that may be useful for debugging an EGD network. The EGD signature and packet size
for the fast EGD exchange is displayed.
b) SLOW EXCHANGE
PATH: ACTUAL VALUES Ö STATUS ÖØ EGD PROTOCOL STATUS Ö PRODUCER STATUS ÖØ SLOW EXCHANGE 1(2)
These values provide information that may be useful for debugging an EGD network. The EGD signature and packet size
for the slow EGD exchanges are displayed.
6.2.16 TELEPROTECTION CHANNEL TESTS
PATH: ACTUAL VALUES Ö STATUS ÖØ TELEPROT CH TESTS
The status information for two channels is shown here.
 DIRECT DEVICES
 STATUS
DIRECT DEVICE 1
STATUS: Offline
Range: Offline, Online
MESSAGE
DIRECT DEVICE 2
STATUS: Offline
Range: Offline, Online
↓
MESSAGE
DIRECT DEVICE 16
STATUS: Offline
Range: Offline, Online
 FAST EXCHANGE 1

FAST EXCHANGE 1
SIGNATURE: 0
MESSAGE
FAST EXCHANGE 1
DATA LENGTH: 0
 SLOW EXCHANGE 1

SLOW EXCHANGE 1
SIGNATURE: 0
MESSAGE
SLOW EXCHANGE 1
DATA LENGTH: 0
 TELEPROT CH TESTS

CHANNEL 1
STATUS: n/a
Range: n/a, FAIL, OK
MESSAGE
CHANNEL 1 LOST
PACKETS: 1
Range: 1 to 65535 in steps of 1
MESSAGE
CHANNEL 2
STATUS: n/a
Range: n/a, FAIL, OK
MESSAGE
CHANNEL 2 LOST
PACKETS: 1
Range: 1 to 65535 in steps of 1
MESSAGE
VALIDITY OF CHANNEL
CONFIGURATION: FAIL
Range: n/a, FAIL, OK
