5-140 F35 Multiple Feeder Protection System GE Multilin
5.6 CONTROL ELEMENTS 5 SETTINGS
5
5.6.8 8-BIT SWITCHES
PATH: SETTINGS ÖØ CONTROL ELEMENTS ÖØ 8-BIT SWITCHES Ö 8-BIT SWITCH 1(6)
This feature allows switching between two input arguments defined by 8 bits each. The bits are specified by FlexLogic™
operands. The feature could be viewed as an integrated two-position switch for 8 logic signals.
Typically this element is applied in conjunction with the Digitizer and 8-bit Comparator features.
• 8BIT SW 1 ARG A0 to 8BIT SW 1 ARG A7: These settings specify FlexLogic™ operands that constitute the first (A)
input of the switch. These operands are routed to the output operands if the control input is in the "Off" position.
• BIT SW 1 ARG B0 to 8BIT SW 1 ARG B7: These settings specify FlexLogic™ operands that constitute the second (B)
input of the switch. These operands are routed to the output operands if the control input is in the "On" position.
• 8BIT SW 1 CONTROL: This setting specifies FlexLogic™ operands to control the routing between the A and B inputs
of the switch. If the control operand is in the "Off" state, the first (A) input is switched to the output. If the control oper-
and is in the "On" state, the second (B) input is switched to the output. The switching takes place instantaneously.
 8-BIT
 SWITCH 1
8BIT SWITCH 1
FUNCTION: Disabled
Range: Disabled, Enabled
MESSAGE
8BIT SW 1 ARG A0:
Off
Range: FlexLogic™ operand
MESSAGE
8BIT SW 1 ARG A1:
Off
Range: FlexLogic™ operand
↓
MESSAGE
8BIT SW 1 ARG A7:
Off
Range: FlexLogic™ operand
MESSAGE
8BIT SW 1 ARG B0:
Off
Range: FlexLogic™ operand
MESSAGE
8BIT SW 1 ARG B1:
Off
Range: FlexLogic™ operand
↓
MESSAGE
8BIT SW 1 ARG B7:
Off
Range: FlexLogic™ operand
MESSAGE
8BIT SW 1 CONTROL:
Off
Range: FlexLogic™ operand
