GE Multilin F35 Multiple Feeder Protection System B-17
APPENDIX B B.4 MEMORY MAPPING
B
Passwords (Read/Write Command)
4000 Command Password Setting 0 to 4294967295 --- 1 F003 0
Passwords (Read/Write Setting)
4002 Setting Password Setting 0 to 4294967295 --- 1 F003 0
Passwords (Read/Write)
4008 Command Password Entry 0 to 4294967295 --- 1 F003 0
400A Setting Password Entry 0 to 4294967295 --- 1 F003 0
Passwords (read only actual values)
4010 Command password status 0 to 1 --- 1 F102 0 (Disabled)
4011 Setting password status 0 to 1 --- 1 F102 0 (Disabled)
Passwords (read/write settings)
4012 Control password access timeout 5 to 480 min. 1 F001 5
4013 Setting password access timeout 5 to 480 min. 1 F001 30
4014 Invalid password attempts 2 to 5 --- 1 F001 3
4015 Password lockout duration 5 to 60 min. 1 F001 5
4016 Password access events 0 to 1 --- 1 F102 0 (Disabled)
User Display Invoke (Read/Write Setting)
4040 Invoke and Scroll Through User Display Menu Operand 0 to 65535 --- 1 F300 0
LED Test (Read/Write Setting)
4048 LED Test Function 0 to 1 --- 1 F102 0 (Disabled)
4049 LED Test Control 0 to 65535 --- 1 F300 0
Preferences (Read/Write Setting)
404F Language 0 to 3 --- 1 F531 0 (English)
4050 Flash Message Time 0.5 to 10 s 0.1 F001 10
4051 Default Message Timeout 10 to 900 s 1 F001 300
4052 Default Message Intensity 0 to 3 --- 1 F101 0 (25%)
4053 Screen Saver Feature 0 to 1 --- 1 F102 0 (Disabled)
4054 Screen Saver Wait Time 1 to 65535 min 1 F001 30
4055 Current Cutoff Level 0.002 to 0.02 pu 0.001 F001 20
4056 Voltage Cutoff Level 0.1 to 1 V 0.1 F001 10
Communications (Read/Write Setting)
407E COM1 minimum response time 0 to 1000 ms 10 F001 0
407F COM2 minimum response time 0 to 1000 ms 10 F001 0
4080 Modbus Slave Address 1 to 254 --- 1 F001 254
4083 RS485 Com1 Baud Rate 0 to 11 --- 1 F112 8 (115200)
4084 RS485 Com1 Parity 0 to 2 --- 1 F113 0 (None)
4085 RS485 Com2 Baud Rate 0 to 11 --- 1 F112 8 (115200)
4086 RS485 Com2 Parity 0 to 2 --- 1 F113 0 (None)
4087 IP Address 0 to 4294967295 --- 1 F003 56554706
4089 IP Subnet Mask 0 to 4294967295 --- 1 F003 4294966272
408B Gateway IP Address 0 to 4294967295 --- 1 F003 56554497
408D Network Address NSAP --- --- --- F074 0
409A DNP Channel 1 Port 0 to 4 --- 1 F177 0 (None)
409B DNP Channel 2 Port 0 to 4 --- 1 F177 0 (None)
409C DNP Address 0 to 65519 --- 1 F001 1
409D Reserved 0 to 1 --- 1 F001 0
409E DNP Client Addresses (2 items) 0 to 4294967295 --- 1 F003 0
40A3 TCP Port Number for the Modbus protocol 1 to 65535 --- 1 F001 502
40A4 TCP/UDP Port Number for the DNP Protocol 1 to 65535 --- 1 F001 20000
40A5 TCP Port Number for the HTTP (Web Server) Protocol 1 to 65535 --- 1 F001 80
40A6 Main UDP Port Number for the TFTP Protocol 1 to 65535 --- 1 F001 69
40A7 Data Transfer UDP Port Numbers for the TFTP Protocol
(zero means “automatic”) (2 items)
0 to 65535 --- 1 F001 0
40A9 DNP Unsolicited Responses Function 0 to 1 --- 1 F102 0 (Disabled)
Table B–9: MODBUS MEMORY MAP (Sheet 10 of 48)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
