GE Multilin F35 Multiple Feeder Protection System B-25
APPENDIX B B.4 MEMORY MAPPING
B
5898 ...Repeated for FlexLogic™ Timer 20
58A0 ...Repeated for FlexLogic™ Timer 21
58A8 ...Repeated for FlexLogic™ Timer 22
58B0 ...Repeated for FlexLogic™ Timer 23
58B8 ...Repeated for FlexLogic™ Timer 24
58C0 ...Repeated for FlexLogic™ Timer 25
58C8 ...Repeated for FlexLogic™ Timer 26
58D0 ...Repeated for FlexLogic™ Timer 27
58D8 ...Repeated for FlexLogic™ Timer 28
58E0 ...Repeated for FlexLogic™ Timer 29
58E8 ...Repeated for FlexLogic™ Timer 30
58F0 ...Repeated for FlexLogic™ Timer 31
58F8 ...Repeated for FlexLogic™ Timer 32
Phase Time Overcurrent (Read/Write Grouped Setting) (6 modules)
5900 Phase Time Overcurrent 1 Function 0 to 1 --- 1 F102 0 (Disabled)
5901 Phase Time Overcurrent 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
5902 Phase Time Overcurrent 1 Input 0 to 1 --- 1 F122 0 (Phasor)
5903 Phase Time Overcurrent 1 Pickup 0 to 30 pu 0.001 F001 1000
5904 Phase Time Overcurrent 1 Curve 0 to 16 --- 1 F103 0 (IEEE Mod Inv)
5905 Phase Time Overcurrent 1 Multiplier 0 to 600 --- 0.01 F001 100
5906 Phase Time Overcurrent 1 Reset 0 to 1 --- 1 F104 0 (Instantaneous)
5907 Phase Time Overcurrent 1 Voltage Restraint 0 to 1 --- 1 F102 0 (Disabled)
5908 Phase TOC 1 Block For Each Phase (3 items) 0 to 65535 --- 1 F300 0
590B Phase Time Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
590C Phase Time Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
590D Reserved (3 items) 0 to 1 --- 1 F001 0
5910 ...Repeated for Phase Time Overcurrent 2
5920 ...Repeated for Phase Time Overcurrent 3
5930 ...Repeated for Phase Time Overcurrent 4
5940 ...Repeated for Phase Time Overcurrent 5
5950 ...Repeated for Phase Time Overcurrent 6
Phase Instantaneous Overcurrent (Read/Write Grouped Setting) (12 modules)
5A00 Phase Instantaneous Overcurrent 1 Function 0 to 1 --- 1 F102 0 (Disabled)
5A01 Phase Instantaneous Overcurrent 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
5A02 Phase Instantaneous Overcurrent 1 Pickup 0 to 30 pu 0.001 F001 1000
5A03 Phase Instantaneous Overcurrent 1 Delay 0 to 600 s 0.01 F001 0
5A04 Phase Instantaneous Overcurrent 1 Reset Delay 0 to 600 s 0.01 F001 0
5A05 Phase IOC1 Block For Phase A 0 to 65535 --- 1 F300 0
5A06 Phase IOC1 Block For Phase B 0 to 65535 --- 1 F300 0
5A07 Phase IOC1 Block For Phase C 0 to 65535 --- 1 F300 0
5A08 Phase Instantaneous Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
5A09 Phase Instantaneous Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
5A0A Reserved (6 items) 0 to 1 --- 1 F001 0
5A10 ...Repeated for Phase Instantaneous Overcurrent 2
5A20 ...Repeated for Phase Instantaneous Overcurrent 3
5A30 ...Repeated for Phase Instantaneous Overcurrent 4
5A40 ...Repeated for Phase Instantaneous Overcurrent 5
5A50 ...Repeated for Phase Instantaneous Overcurrent 6
5A60 ...Repeated for Phase Instantaneous Overcurrent 7
5A70 ...Repeated for Phase Instantaneous Overcurrent 8
5A80 ...Repeated for Phase Instantaneous Overcurrent 9
5A90 ...Repeated for Phase Instantaneous Overcurrent 10
5AA0 ...Repeated for Phase Instantaneous Overcurrent 11
5AB0 ...Repeated for Phase Instantaneous Overcurrent 12
Table B–9: MODBUS MEMORY MAP (Sheet 18 of 48)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
