B-30 F35 Multiple Feeder Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
75A9 ...Repeated for disconnect switch 6
75BE ...Repeated for disconnect switch 7
75D3 ...Repeated for disconnect switch 8
75E8 ...Repeated for disconnect switch 9
75FD ...Repeated for disconnect switch 10
7612 ...Repeated for disconnect switch 11
7627 ...Repeated for disconnect switch 12
763C ...Repeated for disconnect switch 13
7651 ...Repeated for disconnect switch 14
7666 ...Repeated for disconnect switch 15
767B ...Repeated for disconnect switch 16
7690 ...Repeated for disconnect switch 17
76A5 ...Repeated for disconnect switch 18
76BA ...Repeated for disconnect switch 19
76CF ...Repeated for disconnect switch 20
76E4 ...Repeated for disconnect switch 21
76F9 ...Repeated for disconnect switch 22
770E ...Repeated for disconnect switch 23
7723 ...Repeated for disconnect switch 24
User Programmable Pushbuttons (Read/Write Setting) (16 modules)
7B60 User Programmable Pushbutton 1 Function 0 to 2 --- 1 F109 2 (Disabled)
7B61 User Programmable Pushbutton 1 Top Line --- --- --- F202 (none)
7B6B User Programmable Pushbutton 1 On Text --- --- --- F202 (none)
7B75 User Programmable Pushbutton 1 Off Text --- --- --- F202 (none)
7B7F User Programmable Pushbutton 1 Drop-Out Time 0 to 60 s 0.05 F001 0
7B80 User Programmable Pushbutton 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7B81 User Programmable Pushbutton 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7B82 User Programmable Pushbutton 1 LED Operand 0 to 65535 --- 1 F300 0
7B83 User Programmable Pushbutton 1 Autoreset Delay 0 to 600 s 0.05 F001 0
7B84 User Programmable Pushbutton 1 Autoreset Function 0 to 1 --- 1 F102 0 (Disabled)
7B85 User Programmable Pushbutton 1 Local Lock 0 to 65535 --- 1 F300 0
7B86 User Programmable Pushbutton 1 Message Priority 0 to 2 --- 1 F220 0 (Disabled)
7B87 User Programmable Pushbutton 1 Remote Lock 0 to 65535 --- 1 F300 0
7B88 User Programmable Pushbutton 1 Reset 0 to 65535 --- 1 F300 0
7B89 User Programmable Pushbutton 1 Set 0 to 65535 --- 1 F300 0
7B8A User Programmable Pushbutton 1 Hold 0 to 10 s 0.1 F001 1
7B8B ...Repeated for User Programmable Pushbutton 2
7BB6 ...Repeated for User Programmable Pushbutton 3
7BE1 ...Repeated for User Programmable Pushbutton 4
7C0C ...Repeated for User Programmable Pushbutton 5
7C37 ...Repeated for User Programmable Pushbutton 6
7C62 ...Repeated for User Programmable Pushbutton 7
7C8D ...Repeated for User Programmable Pushbutton 8
7CB8 ...Repeated for User Programmable Pushbutton 9
7CE3 ...Repeated for User Programmable Pushbutton 10
7D0E ...Repeated for User Programmable Pushbutton 11
7D39 ...Repeated for User Programmable Pushbutton 12
7D64 ...Repeated for User Programmable Pushbutton 13
7D8F ...Repeated for User Programmable Pushbutton 14
7DBA ...Repeated for User Programmable Pushbutton 15
7DE5 ...Repeated for User Programmable Pushbutton 16
Underfrequency (Read/Write Setting) (6 modules)
7E10 Underfrequency Function 0 to 1 --- 1 F102 0 (Disabled)
7E11 Underfrequency 1 Block 0 to 65535 --- 1 F300 0
Table B–9: MODBUS MEMORY MAP (Sheet 23 of 48)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
