GE Multilin F35 Multiple Feeder Protection System B-33
APPENDIX B B.4 MEMORY MAPPING
B
8AB4 ...Repeated for Digital Element 10
8AC8 ...Repeated for Digital Element 11
8ADC ...Repeated for Digital Element 12
8AF0 ...Repeated for Digital Element 13
8B04 ...Repeated for Digital Element 14
8B18 ...Repeated for Digital Element 15
8B2C ...Repeated for Digital Element 16
8B40 ...Repeated for Digital Element 17
8B54 ...Repeated for Digital Element 18
8B68 ...Repeated for Digital Element 19
8B7C ...Repeated for Digital Element 20
8B90 ...Repeated for Digital Element 21
8BA4 ...Repeated for Digital Element 22
8BB8 ...Repeated for Digital Element 23
8BCC ...Repeated for Digital Element 24
8BE0 ...Repeated for Digital Element 25
8BF4 ...Repeated for Digital Element 26
8C08 ...Repeated for Digital Element 27
8C1C ...Repeated for Digital Element 28
8C30 ...Repeated for Digital Element 29
8C44 ...Repeated for Digital Element 30
8C58 ...Repeated for Digital Element 31
8C6C ...Repeated for Digital Element 32
8C80 ...Repeated for Digital Element 33
8C94 ...Repeated for Digital Element 34
8CA8 ...Repeated for Digital Element 35
8CBC ...Repeated for Digital Element 36
8CD0 ...Repeated for Digital Element 37
8CE4 ...Repeated for Digital Element 38
8CF8 ...Repeated for Digital Element 39
8D0C ...Repeated for Digital Element 40
8D20 ...Repeated for Digital Element 41
8D34 ...Repeated for Digital Element 42
8D48 ...Repeated for Digital Element 43
8D5C ...Repeated for Digital Element 44
8D70 ...Repeated for Digital Element 45
8D84 ...Repeated for Digital Element 46
8D98 ...Repeated for Digital Element 47
8DAC ...Repeated for Digital Element 48
Trip Bus (Read/Write Setting)
8E00 Trip Bus 1 Function 0 to 1 --- 1 F102 0 (Disabled)
8E01 Trip Bus 1 Block --- --- --- F300 0
8E02 Trip Bus 1 Pickup Delay 0 to 600 s 0.01 F001 0
8E03 Trip Bus 1 Reset Delay 0 to 600 s 0.01 F001 0
8E04 Trip Bus 1 Input 1 0 to 65535 --- 1 F300 0
8E05 Trip Bus 1 Input 2 0 to 65535 --- 1 F300 0
8E06 Trip Bus 1 Input 3 0 to 65535 --- 1 F300 0
8E07 Trip Bus 1 Input 4 0 to 65535 --- 1 F300 0
8E08 Trip Bus 1 Input 5 0 to 65535 --- 1 F300 0
8E09 Trip Bus 1 Input 6 0 to 65535 --- 1 F300 0
8E0A Trip Bus 1 Input 7 0 to 65535 --- 1 F300 0
8E0B Trip Bus 1 Input 8 0 to 65535 --- 1 F300 0
8E0C Trip Bus 1 Input 9 0 to 65535 --- 1 F300 0
8E0D Trip Bus 1 Input 10 0 to 65535 --- 1 F300 0
Table B–9: MODBUS MEMORY MAP (Sheet 26 of 48)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
