GE Multilin F35 Multiple Feeder Protection System B-35
APPENDIX B B.4 MEMORY MAPPING
B
9205 Fault Report 1 Z0 Angle 25 to 90 degrees 1 F001 75
9206 Fault Report 1 Line Length Units 0 to 1 --- 1 F147 0 (km)
9207 Fault Report 1 Line Length 0 to 2000 0.1 F001 1000
9208 Fault Report 1 VT Substitution 0 to 2 --- 1 F270 0 (None)
9208 Fault Report 1 System Z0 Magnitude 0.01 to 650.00 ohms 0.01 F001 900
9208 Fault Report 1 System Z0 Angle 25 to 90 degrees 1 F001 75
920B ...Repeated for Fault Report 2
9216 ...Repeated for Fault Report 3
9221 ...Repeated for Fault Report 4
922C ...Repeated for Fault Report 5
dcmA Outputs (Read/Write Setting) (24 modules)
9300 dcmA Output 1 Source 0 to 65535 --- 1 F600 0
9301 dcmA Output 1 Range 0 to 2 --- 1 F522 0 (–1 to 1 mA)
9302 dcmA Output 1 Minimum –90 to 90 pu 0.001 F004 0
9304 dcmA Output 1 Maximum –90 to 90 pu 0.001 F004 1000
9306 ...Repeated for dcmA Output 2
930C ...Repeated for dcmA Output 3
9312 ...Repeated for dcmA Output 4
9318 ...Repeated for dcmA Output 5
931E ...Repeated for dcmA Output 6
9324 ...Repeated for dcmA Output 7
932A ...Repeated for dcmA Output 8
9330 ...Repeated for dcmA Output 9
9336 ...Repeated for dcmA Output 10
933C ...Repeated for dcmA Output 11
9342 ...Repeated for dcmA Output 12
9348 ...Repeated for dcmA Output 13
934E ...Repeated for dcmA Output 14
9354 ...Repeated for dcmA Output 15
935A ...Repeated for dcmA Output 16
9360 ...Repeated for dcmA Output 17
9366 ...Repeated for dcmA Output 18
936C ...Repeated for dcmA Output 19
9372 ...Repeated for dcmA Output 20
9378 ...Repeated for dcmA Output 21
937E ...Repeated for dcmA Output 22
9384 ...Repeated for dcmA Output 23
938A ...Repeated for dcmA Output 24
Direct Input/Output Names (Read/Write Setting) (96 modules)
9400 Direct Input 1 Name 0 to 96 --- 1 F205 “Dir Ip 1”
9406 Direct Output 1 Name 1 to 96 --- 1 F205 “Dir Out 1”
940C ...Repeated for Direct Input/Output 2
9418 ...Repeated for Direct Input/Output 3
9424 ...Repeated for Direct Input/Output 4
9430 ...Repeated for Direct Input/Output 5
943C ...Repeated for Direct Input/Output 6
9448 ...Repeated for Direct Input/Output 7
9454 ...Repeated for Direct Input/Output 8
9460 ...Repeated for Direct Input/Output 9
946C ...Repeated for Direct Input/Output 10
9478 ...Repeated for Direct Input/Output 11
9484 ...Repeated for Direct Input/Output 12
9490 ...Repeated for Direct Input/Output 13
949C ...Repeated for Direct Input/Output 14
Table B–9: MODBUS MEMORY MAP (Sheet 28 of 48)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
