B.4 MEMORY MAPPING APPENDIX B
B
5 Phase Instantaneous Overcurrent 6
6 Phase Instantaneous Overcurrent 7
7 Phase Instantaneous Overcurrent 8
8 Phase Instantaneous Overcurrent 9
9 Phase Instantaneous Overcurrent 10
10 Phase Instantaneous Overcurrent 11
11 Phase Instantaneous Overcurrent 12
16 Phase Time Overcurrent 1
17 Phase Time Overcurrent 2
18 Phase Time Overcurrent 3
19 Phase Time Overcurrent 4
20 Phase Time Overcurrent 5
21 Phase Time Overcurrent 6
24 Phase Directional Overcurrent 1
25 Phase Directional Overcurrent 2
32 Neutral Instantaneous Overcurrent 1
33 Neutral Instantaneous Overcurrent 2
34 Neutral Instantaneous Overcurrent 3
35 Neutral Instantaneous Overcurrent 4
36 Neutral Instantaneous Overcurrent 5
37 Neutral Instantaneous Overcurrent 6
38 Neutral Instantaneous Overcurrent 7
39 Neutral Instantaneous Overcurrent 8
40 Neutral Instantaneous Overcurrent 9
41 Neutral Instantaneous Overcurrent 10
42 Neutral Instantaneous Overcurrent 11
43 Neutral Instantaneous Overcurrent 12
48 Neutral Time Overcurrent 1
49 Neutral Time Overcurrent 2
50 Neutral Time Overcurrent 3
51 Neutral Time Overcurrent 4
52 Neutral Time Overcurrent 5
53 Neutral Time Overcurrent 6
56 Neutral Directional Overcurrent 1
57 Neutral Directional Overcurrent 2
60 Negative Sequence Directional Overcurrent 1
61 Negative Sequence Directional Overcurrent 2
64 Ground Instantaneous Overcurrent 1
65 Ground Instantaneous Overcurrent 2
66 Ground Instantaneous Overcurrent 3
67 Ground Instantaneous Overcurrent 4
68 Ground Instantaneous Overcurrent 5
69 Ground Instantaneous Overcurrent 6
70 Ground Instantaneous Overcurrent 7
71 Ground Instantaneous Overcurrent 8
72 Ground Instantaneous Overcurrent 9
73 Ground Instantaneous Overcurrent 10
74 Ground Instantaneous Overcurrent 11
75 Ground Instantaneous Overcurrent 12
80 Ground Time Overcurrent 1
81 Ground Time Overcurrent 2
82 Ground Time Overcurrent 3
83 Ground Time Overcurrent 4
bitmask element
84 Ground Time Overcurrent 5
85 Ground Time Overcurrent 6
96 Negative Sequence Instantaneous Overcurrent 1
97 Negative Sequence Instantaneous Overcurrent 2
101 Opposite Phase Rotation
112 Negative Sequence Time Overcurrent 1
113 Negative Sequence Time Overcurrent 2
120 Negative Sequence Overvoltage
140 Auxiliary Undervoltage 1
144 Phase Undervoltage 1
145 Phase Undervoltage 2
148 Auxiliary Overvoltage 1
152 Phase Overvoltage 1
156 Neutral Overvoltage 1
232 SRC1 50DD (Disturbance Detection)
233 SRC2 50DD (Disturbance Detection)
234 SRC3 50DD (Disturbance Detection)
235 SRC4 50DD (Disturbance Detection)
236 SRC5 50DD (Disturbance Detection)
237 SRC6 50DD (Disturbance Detection)
280 Breaker Failure 1
281 Breaker Failure 2
282 Breaker Failure 3
283 Breaker Failure 4
284 Breaker Failure 5
285 Breaker Failure 6
288 Breaker Arcing Current 1
289 Breaker Arcing Current 2
290 Breaker Arcing Current 3
291 Breaker Arcing Current 4
292 Breaker Arcing Current 5
293 Breaker Arcing Current 6
304 Autoreclose 1
305 Autoreclose 2
306 Autoreclose 3
307 Autoreclose 4
308 Autoreclose 5
309 Autoreclose 6
336 Setting Group
337 Reset
352 Underfrequency 1
353 Underfrequency 2
354 Underfrequency 3
355 Underfrequency 4
356 Underfrequency 5
357 Underfrequency 6
375 Autoreclose (single-pole / three-pole)
388 Selector 1
389 Selector 2
390 Control pushbutton 1
391 Control pushbutton 2
392 Control pushbutton 3
393 Control pushbutton 4
bitmask element
