B-62 F35 Multiple Feeder Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F142
ENUMERATION: EVENT RECORDER ACCESS FILE TYPE
0 = All Record Data, 1 = Headers Only, 2 = Numeric Event Cause
F143
UR_UINT32: 32 BIT ERROR CODE (F141 specifies bit number)
A bit value of 0 = no error, 1 = error
F144
ENUMERATION: FORCED CONTACT INPUT STATE
0 = Disabled, 1 = Open, 2 = Closed
F145
ENUMERATION: ALPHABET LETTER
F146
ENUMERATION: MISCELLANEOUS EVENT CAUSES
F148
ENUMERATION: FAULT TYPE
47 Module Failure 07
48 Module Failure 08
49 Module Failure 09
50 Incompatible H/W
51 Maintenance Alert
52 Maintenance Alert
53 Maintenance Alert
54 Maintenance Alert
55 Maintenance Alert
56 Maintenance Alert
bitmask type bitmask type bitmask type bitmask type
0 null 7 G 14 N 21 U
1A 8H 15O 22V
2B 9 I 16P 23W
3 C 10 J 17 Q 24 X
4D 11K 18R 25Y
5 E 12 L 19 S 26 Z
6F 13M 20T
bitmask error
bitmask definition
0 Events Cleared
1 Oscillography Triggered
2 Date/time Changed
3 Default Settings Loaded
4 Test Mode On
5 Test Mode Off
6 Power On
7 Power Off
8 Relay In Service
9 Relay Out Of Service
10 Watchdog Reset
11 Oscillography Clear
12 Reboot Command
13 Led Test Initiated
14 Flash Programming
15 Fault Report Trigger
16 User Programmable Fault Report Trigger
17 Corrupt DSP Program
18 Reload DSP Settings
19 DSP Hardware Error
20 Ethernet Port 1 Offline
21 Ethernet Port 2 Offline
22 Ethernet Port 3 Offline
23 Ethernet Port 4 Offline
24 Ethernet Port 5 Offline
25 Ethernet Port 6 Offline
bitmask fault type bitmask fault type
0NA 6AC
1AG 7ABG
2BG 8BCG
3CG 9ACG
4 AB 10 ABC
5BC 11ABCG
