5-24 469 Motor Management Relay GE Power Management
5.6 A5 EVENT RECORDER 5 ACTUAL VALUES
5
The event recorder stores motor and system information each time an event occurs. An event description is
stored along with a time and date stamp for troubleshooting purposes. Events include all trips, any alarm
optionally (except Service Alarm, and 469 Not Inserted Alarm, which always records as events), loss of control
power, application of control power, emergency restarts, and motor starts when a blocking function is active.
The latter event could occur if the block start contacts were shorted out to bypass the 469 and start the motor.
EVENT 01
is the most recent event and
EVENT 40
is the oldest event. Each new event bumps the other event
records up one until
EVENT 40
is reached. The event record in
EVENT 40
is lost when a new event occurs. This
information can be cleared using the
S1 469 SETUP \ CLEAR DATA \ CLEAR EVENT RECORD
setpoint.
ANALOG I/P 1
EVENT01: 0 Units
Range: –50000 to 50000
ANALOG I/P 2
EVENT01: 0 Units
Range: –50000 to 50000
ANALOG I/P 3
EVENT01: 0 Units
Range: –50000 to 50000
ANALOG I/P 4
EVENT01: 0 Units
Range: –50000 to 50000
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
