GE Power Management 469 Motor Management Relay 5-25
5 ACTUAL VALUES 5.6 A5 EVENT RECORDER
5
Table 5–4: CAUSE OF EVENTS
TRIPS ALARMS (OPTIONAL EVENTS) OTHER
Incomplete Seq Trip Remote Alarm Service Alarm
Remote Trip Pressure Sw. Alarm Control Power Lost
Speed Switch Trip Vibration Sw. Alarm Control Power Applied
Load Shed Trip Counter Alarm Emergency Rst.Close
Pressure Sw. Trip Tachometer Alarm Emergency Rst. Open
Vibration Sw.Trip General Sw.A Alarm Start While Blocked
Tachometer Trip General Sw.B Alarm 469 Not Inserted
General Sw.A Trip General Sw.C Alarm Simulation Started
General Sw.B Trip General Sw.D Alarm Simulation Stopped
General Sw.C Trip Thermal Model Alarm Forced Relay
General Sw.D Trip Overload Alarm
Overload Trip Undercurrent Alarm
Short Circuit Trip Current U/B Alarm
Short Circuit Backup Ground Fault Alarm
Mechanical Jam Trip Stator RTD 1 Alarm
Undercurrent Trip Stator RTD 2 Alarm
Current U/B Trip Stator RTD 3 Alarm
Ground Fault Trip Stator RTD 4 Alarm
Ground Fault Backup Stator RTD 5 Alarm
Differential Trip Stator RTD 6 Alarm
Acceleration Trip Bearing RTD 7 Alarm
Stator RTD 1 Trip Bearing RTD 8 Alarm
Stator RTD 2 Trip Bearing RTD 9 Alarm
Stator RTD 3 Trip Bearing RTD10 Alarm
Stator RTD 4 Trip RTD11 Alarm
Stator RTD 5 Trip Ambient RTD12 Alarm
Stator RTD 6 Trip Open RTD Alarm
Bearing RTD 7 Trip Short/Low RTD Alarm
Bearing RTD 8 Trip Undervoltage Alarm
Bearing RTD 9 Trip Overvoltage Alarm
Bearing RTD10 Trip Volt. Frequency Alarm
RTD11 Trip Reactive Power Alarm
Ambient RTD12 Trip Underpower Alarm
Undervoltage Trip Trip Counter Alarm
Overvoltage Trip Trip Coil Super
Phase Reversal Trip Welded Contactor
Volt. Frequency Trip Breaker Failure
Reactive Power Trip Current Demand Alarm
Power Factor Trip kW Demand Alarm
Underpower Trip kvar Demand Alarm
Analog I/P 1 to 4 Trip kVA Demand Alarm
Single Phasing (Unbalanced) Analog I/P 1 to 4 Alarm
Overtorque
