6-24 469 Motor Management Relay GE Power Management
6.4 MEMORY MAP 6 COMMUNICATIONS
6
POWER
METERING
continued
0376 Apparent Power 0 65535 1 kVA F1 0
0377 MWh Consumption 0 999999999 1 MWh F17 0
0379 Mvarh Consumption 0 999999999 1 Mvarh F17 0
037B Mvarh Generation 0 999999999 1 Mvarh F17 0
037D Torque 0 9999999 1 Nm/ftlb F10 0
037F Reserved
... ...
038F Reserved
DEMAND
METERING
0390 Current Demand 0 100000 1 A F9 0
0392 Real Power Demand –50000 50000 1 kW F12 0
0394 Reactive Power Demand –50000 50000 1 kvar F12 0
0396 Apparent Power Demand 0 50000 1 kVA F1 0
0397 Peak Current Demand 0 100000 1 A F9 0
0399 Peak Real Power Demand –50000 50000 1 kW F12 0
039B Peak Reactive Power Demand –50000 50000 1 kvar F12 0
039D Peak Apparent Power Demand 0 50000 1 kVA F1 0
039E Reserved
...
03AF Reserved
ANALOG
INPUTS
03B0 Analog I/P 1 –50000 50000 1 - F12 0
03B2 Analog I/P 2 –50000 50000 1 - F12 0
03B4 Analog I/P 3 –50000 50000 1 - F12 0
03B6 Analog I/P 4 –50000 50000 1 - F12 0
03B8 Analog Diff 1-2 Absolute –100000 100000 1 - F12 0
03BA Analog Diff 3-4 Absolute –100000 100000 1 - F12 0
03BC Reserved
... ...
03BF Reserved
MOTOR
STARTING
03C0 Learned Acceleration Time 0 2000 1 s F2 0
03C1 Learned Starting Current 0 50000 1 A F9 0
03C3 Learned Starting Capacity 0 100 1 % F1 0
03C4 Last Acceleration Time 0 2000 1 s F2 0
03C5 Last Starting Current 0 50000 1 A F9 0
03C7 Last Starting Capacity 0 100 1 % F1 0
03C8 Reserved
... ...
03CF Reserved
AVERAGE
MOTOR LOAD
03D0 Average Motor Load Learned 0 2000 1
×
FLA F3 5
03D1 Reserved
... ...
03DF Reserved
Table 6–1: 469 MEMORY MAP (Sheet 7 of 43)
GROUP ADDR
(HEX)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
DEFAULT
