6.4 MEMORY MAP 6 COMMUNICATIONS
6
81 Volt. Frequency Alarm
82 Power Factor Alarm
83 Reactive Power Alarm
84 Underpower Alarm
85 Trip Counter Alarm
86 Starter Failed Alarm
87 Current Demand Alarm
88 kW Demand Alarm
89 kvar Demand Alarm
90 kVA Demand Alarm
91 Broken Rotor Bar
92 Analog I/P 1 Alarm
93 Analog I/P 2 Alarm
94 Analog I/P 3 Alarm
95 Analog I/P 4 Alarm
96 Reverse Power Alarm
97 Incomplete Sequence Alarm
98 Analog Differential 1-2 Alarm
99 Analog Differential 3-4 Alarm
↓↓
101 Service Alarm
102 Control Power Lost
103 Cont. Power Applied
104 Emergency Rst. Close
105 Emergency Rst. Open
106 Start While Blocked
107 Relay Not Inserted
108 Trip Coil Super.
109 Breaker Failure
110 Welded Contactor
111 Simulation Started
112 Simulation Stopped
↓↓
118 Digital Trace Trigger
119 Serial Trace Trigger
120 RTD 1 High Alarm
121 RTD 2 High Alarm
122 RTD 3 High Alarm
123 RTD 4 High Alarm
124 RTD 5 High Alarm
125 RTD 6 High Alarm
126 RTD 7 High Alarm
127 RTD 8 High Alarm
128 RTD 9 High Alarm
129 RTD 10 High Alarm
Table 6–2: MEMORY MAP DATA FORMATS (Sheet 11 of 14)
FORMAT
CODE
TYPE DEFINITION
130 RTD 11 High Alarm
131 RTD 12 High Alarm
132 Overtorque Alarm
133 R1 Relay Forced
134 R2 Relay Forced
135 R3 Relay Forced
136 R4 Relay Forced
137 R5 Relay Forced
138 Force R1 Disabled
139 Force R2 Disabled
140 Force R3 Disabled
141 Force R4 Disabled
142 Force R5 Disabled
143 Motor Started
FC135 Unsigned
16 bit integer
MOTOR SPEED
0 Low Speed (Speed 1)
1 High Speed (Speed 2)
FC136 Unsigned
16 bit integer
ORDER CODE
Bit 0 0 - Code P5 (5A phase CT),
1 - Code P1 (1A phase CT)
Bit 1 0 - Code HI (High Voltage Power Supply),
1 - Code LO (Low Voltage Power Supply)
Bit 2 0 - Code A20 (4-20 mA Analog Outputs),
1 - Code A1 (0-1 mA Analog Outputs)
FC137 Unsigned
16 bit integer
CONTROL RELAYS FOR REDUCED VOLTAGE
STARTING
0 Auxiliary 2
1 Auxiliary 2 & Auxiliary 3
2 Auxiliary 3
FC138 Unsigned
16 bit integer
SIMULATION MODE
0Off
1 Simulate Pre-Fault
2Simulate Fault
3Pre-Fault to Fault
FC139 Unsigned
16 bit integer
FORCE OPERATION OF RELAYS
0Disabled
1R1 Trip
2R2 Auxiliary
3R3 Auxiliary
4R4 Alarm
5R5 Block Start
6R6 Service
Table 6–2: MEMORY MAP DATA FORMATS (Sheet 12 of 14)
FORMAT
CODE
TYPE DEFINITION
