GE Power Management 469 Motor Management Relay 6-65
6 COMMUNICATIONS 6.4 MEMORY MAP
6
FC133 Unsigned
16 bit integer
MOTOR STATUS
0 Stopped
1Starting
2 Running
3Overloaded
4Tripped
FC134 Unsigned
16 bit integer
CAUSE OF EVENT /
CAUSE OF LAST TRIP (UP TO 45)
0No Event / No Trip To Date
1 Incomplete Sequence Trip
2Remote Trip
3 Speed Switch Trip
4Load Shed Trip
5Pressure Sw. Trip
6 Vibration Sw. Trip
7 Tachometer Trip
8 General Sw. A Trip
9 General Sw. B Trip
10 General Sw. C Trip
11 General Sw. D Trip
12 Overload Trip
13 Short Circuit Trip
14 Short Circuit Backup
15 Mechanical Jam Trip
16 Undercurrent Trip
17 Current U/B Trip
18 Ground Fault Trip
19 Ground Fault Backup
20 Differential Trip
21 Acceleration Trip
22 RTD 1 Trip
23 RTD 2 Trip
24 RTD 3 Trip
25 RTD 4 Trip
26 RTD 5 Trip
27 RTD 6 Trip
28 RTD 7 Trip
29 RTD 8 Trip
30 RTD 9 Trip
31 RTD 10 Trip
32 RTD 11 Trip
33 RTD 12 Trip
34 Undervoltage Trip
35 Overvoltage Trip
Table 6–2: MEMORY MAP DATA FORMATS (Sheet 9 of 14)
FORMAT
CODE
TYPE DEFINITION
36 Phase Reversal Trip
37 Volt. Frequency Trip
38 Power Factor Trip
39 Reactive Power Trip
40 Underpower Trip
41 Analog I/P 1 Trip
42 Analog I/P 2 Trip
43 Analog I/P 3 Trip
44 Analog I/P 4 Trip
45 Single Phasing Trip
46 Reverse Power Trip
47 Field Circuit Open Trip
48 Analog Differential 1-2 Trip
49 Analog Differential 3-4 Trip
50 ----
51 Remote Alarm
52 Pressure Sw. Alarm
53 Vibration Sw. Alarm
54 Counter Alarm
55 Tachometer Alarm
56 General Sw. A Alarm
57 General Sw. B Alarm
58 General Sw. C Alarm
59 General Sw. D Alarm
60 Thermal Model Alarm
61 Overload Alarm
62 Undercurrent Alarm
63 Current U/B Alarm
64 Ground Fault Alarm
65 RTD 1 Alarm
66 RTD 2 Alarm
67 RTD 3 Alarm
68 RTD 4 Alarm
69 RTD 5 Alarm
70 RTD 6 Alarm
71 RTD 7 Alarm
72 RTD 8 Alarm
73 RTD 9 Alarm
74 RTD 10 Alarm
75 RTD 11 Alarm
76 RTD 12 Alarm
77 Open RTD Alarm
78 Short/Low RTD Alarm
79 Undervoltage Alarm
80 Overvoltage Alarm
Table 6–2: MEMORY MAP DATA FORMATS (Sheet 10 of 14)
FORMAT
CODE
TYPE DEFINITION
