6.4 MEMORY MAP 6 COMMUNICATIONS
6
FC123 Unsigned
16 bit integer
ALARM STATUS
0Off
1Not Active
2 Timing Out
3Active
4Latched
FC124 Unsigned
16 bit integer
PHASE ROTATION AT MOTOR TERMINALS
0ABC
1BAC
FC125 Unsigned
16 bit integer
STARTER TYPE
0Breaker
1Contactor
FC126 Unsigned
16 bit integer
DISABLED / ENABLED SELECTION
0Disabled
1Enabled
FC127 Unsigned
16 bit integer
ANALOG OUTPUT PARAMETER SELECTION
0None
1Phase A Current
2Phase B Current
3 Phase C Current
4 Average Phase Current
5AB Line Voltage
6BC Line Voltage
7CA Line Voltage
8Average Line Voltage
9Phase AN Voltage
10 Phase BN Voltage
11 Phase CN Voltage
12 Average Phase Voltage
13 Hottest Stator RTD
14 Hottest Bearing RTD
15 Ambient RTD
16 RTD #1
17 RTD #2
18 RTD #3
19 RTD #4
20 RTD #5
21 RTD #6
22 RTD #7
23 RTD #8
24 RTD #9
Table 6–2: MEMORY MAP DATA FORMATS (Sheet 7 of 14)
FORMAT
CODE
TYPE DEFINITION
25 RTD #10
26 RTD #11
27 RTD #12
28 Power Factor
29 Reactive Power
30 Real Power (kW)
31 Apparent Power
32 Thermal Capacity Used
33 Relay Lockout Time
34 Current Demand
35 kvar Demand
36 kW Demand
37 kVA Demand
38 Motor Load
39 Analog Input 1
40 Analog Input 2
41 Analog Input 3
42 Analog Input 4
43 Tachometer
44 MWhrs
45 Analog In Diff 1-2
46 Analog In Diff 3-4
FC128 Unsigned
16 bit integer
PROTECTION CURVE STYLE SELECTION
0 Standard
1Custom
2Voltage Dependent
FC129 Unsigned
16 bit integer
ANALOG INPUT SELECTION
0Disabled
14-20 mA
20-20 mA
30-1 mA
FC130 Unsigned
16 bit integer
PICKUP TYPE
0Over
1Under
FC131 Unsigned
16 bit integer
INPUT SWITCH STATUS
0Open
1Shorted
FC132 Unsigned
16 bit integer
TRIP COIL SUPERVISION STATUS
0No Coil
1Coil
